Interchangeable Core Bottom Pin (.108 Diameter) Product Data Sheet

LAB BEST IC Bottom Pin Design:

• Available in sizes to meet A-2, A-3, A-4 system requirements
• NICKEL SILVER MATERIAL
• For use with all BEST Interchangeable Cores
• Increased Flat Nose design to give positive key function

Packaging:

Polybags only (standard pack 100, large pack 1000, jumbo pack 5000, and factory pack 50,000)

LAB Original IC Bottom Pin Design:

• Available in sizes to meet A-2, A-3, A-4 system requirements
• NICKEL SILVER MATERIAL
• For use with all IC using Nickel Silver Keys (EXCEPT BEST). For example Falcon, Schlage Small Format, Medeco KeyMark etc.
• Radius to flat transition to decrease key / pin wear

Packaging:

Polybags only (standard pack 100, large pack 1000, jumbo pack 5000, and factory pack 50,000)

LAB Universal IC Bottom Pin Design:

• Available in sizes to meet A-2, A-3, A-4 system requirements
• BRASS MATERIAL (Full Hard)
• A-2 Color Coded for easy use
• Radius nose design for decreased key insertion forces

Packaging:

Vials and Smart Pac only (qty. 100)
