Door Loops

BUILD-A-DOOR LOOP

Whether you have specific needs for a custom Door Loop set-up, or need parts to have on hand at all times to create exactly what you need for each job, Keedex has you covered.

If you are putting together a single door loop set up, pick your flex conduit type from group A, the corresponding sized connector base from group B¹ or B², and the cover color you desire from group C.

(if you select the Stainless Steel End Caps in B² you do NOT need to pick a product from group C)

Flex Conduit Bulk

• A) K-FLX......1/4" Steel 50'-250'* (USA)
• B) K-FLX38......3/8" Steel 50'-250'* (USA)
• C) K-DS-FLX......1/4" x 18'Stainless Steel (CHINA)
• D) K-USS-FLX.....1/4" Stainless Steel (USA) 50'-250'*
• E) K-DS-FLX38...3/8"x 18' Stainless Steel (CHINA)
• F) K-USS-FLX38..3/8" Stainless Steel (USA) 50'-250'*
• G) K-FLX-A ......1/4" Aluminum sold per foot
• H) K-FLX38-A..... 3/8" Aluminum sold per foot
• I) K-FLX-B ......1/4" Duranodic sold per foot**
• J) K-FLX-BLK......1/4" Black sold per foot**
• K) K-FLX-G.....1/4" Gold sold per foot**

*50' Increments up to 250'

All powder-coated flex noted above is made from U.S. Steel (K-FLX & K-FLX38)

A, G, I, J, K,		D.
В,		E.
C.		F.

K-DLCK K-DLCK38

Finish: bare aluminum

Set of 2 Stainless Steel End Caps with stainless screws

K-DS-EC K-DS38-EC

POWDER COAT DURANODIC

K-DS-EC-B K-DS38-EC-B

POWDER COAT BLACK

K-DS-EC-BLK K-DS38-EC-BLK

Door Loop Covers

** not pictured

Choose only if you select from group B1

K-DLACOVER-Powder coated Aluminum K-DLBCOVER-Powder coated Duranodic

K-DL3COVER- Bright Brass

K-DL26COVER- Bright Chrome

K-DLGCOVER- Gold

K-DLBLKCOVER- Black

K-DLWCOVER-White
