IDC 7300-G1 Series Rim Exit Device Specification Sheet

Open the original PDF document

DESIGNED FOR ALUMINUM, HOLLOW METAL AND WOOD DOORS

GRADE 1 • RIM PANIC

Grade 1
Underwriter's Laboratories Inc. Listed Panic Hardware
For use with narrow, medium and wide stile Aluminum doors, Hollow Metal or Wood Doors
Non-handed, for LHRB or RHRB doors
Latch Bolt throw 5/8"
Dogging by Hex Key in Touch Bar
Outside Unlatching with standard Rim Cylinder
Standard units for 36" and 48" door widths ( cut bar to fit )
Can be used on 30" wide doors

PH-6000 Outside Pull Handle

AL - ALUMINUM- Anodized extruded Aluminum with Baked Aluminum Painted Cover Caps

DU- STOREFRONT BRONZE- Bronze Anodized extruded Aluminum with Baked Storefront Bronze Painted Cover Caps

WARRANTY: Refer to inside front cover

MP-6000 Pull Handle Mounting Plate for Wood or Metal Doors

RZ-1003 Rim Cylinder

Finishes Available:

AL - Anodized Satin Aluminum

BK - Anodized Black

DU - Anodized Bronze

Specify: Finish

West: 800-544-4422 • East: 800-225-6737
