View PDFHow to Order KMS-STP
Heavy-Duty Deadbolt
| QTY | SERIES | FAMILY | FUNCTION | FINISH | BACKSET | STRIKE | CYLINDER | KEYWAY | KEYING |
|---|---|---|---|---|---|---|---|---|---|
| KMS | STP | 116 | 626 | ADJ | DB | D | SCC | KD | |
| 605 | 234 - 2-3/4" |
D
- Default |
KW |
KD
- Keyed |
|||||
| 613 | 238 - 2-3/8" |
L
- Less |
622
|
238 - 2-3/8"
ADJ - Adjustable 2-3/4"– 2-3/8" ADJR - Ad justable 2-3/4"–2- 3/8" Radius |
D
- Default L - Less Cylinder SF6 - SFIC w/Core, 6 Pin SF7 - SFIC w/Core, 7 Pin SF7L - SFIC 7 Pin Housing, Less Core SF6L - SFIC 6 Pin Housing, Less Core |
KW |
KD
- Keyed KO - Zero Bitted KA - Keyed Alike KE - Keyed to Existing MK - Master Key CMK - Construction Master Key |
