PANEL READER

WRDxx | MULLION READER

The SALTO Panel reader 2.0 is a based door entry system that works in conjunction with SALTO controllers.

Designed to be integrated behind lift panels, door intercoms, electric switches or turnstiles & gates. These models need a window, which is necessary for reader antenna operation.

FEATURES:

• Specially designed to be integrated behind lifts panels, door intercoms, electric switches,….
• Two stickers & labels are available for visible signage.
• Reader is housed in a onepiece, weatherproof secure electronics potted enclosure.
• Fully integrated with the SALTO XS4 platform.
• Virtual network capable through SALTO SVN data-on-card technology.
• Acoustic and optical signalling, dual colour green/red to indicate access authorisation.
• Blue light indicates that the user key update is in progress through SALTO Virtual Network technology.

COVER STICKER FINISHES

CERTIFICATIONS

QTY Please Circle One FOH / BOH / N-A

TECHNICAL CHARACTERISTICS:

• To be used in combination with XS4 2.0 controllers (CU42xxx).
• Maximum distance between the door controller and the wall reader 400m using a twisted pair cable.
• Connection to the door controller: 4 wires.
• Designed to work with an online SVN access control platform, or with a stand-alone system.
• Includes tamper to monitor if the wall reader has been opened.
• Reading distance from 35 to 50mm depending on the RFID technology.

TECHNOLOGY PLATFORMS:

SALTO SPACE
SALTO KS

ID TECHNOLOGIES :

• MIFARE® (DESFire EV1, Plus, Ultralight C, Classic ISO/IEC 14443).
• Bluetooth SMART (BLE).
• NFC.
• HID iCLASS®.

REFERENCE GUIDE

• To create the SALTO part number for the order, please circle one element under each column.

Product Type	Model	Technoloty	Stickers (included)
WRD Wall Reader	B MIFARE BLE	0P4	0
	J HID iClass BLE
