HID iCLASS SE Biometric Reader HID Elite Key User Guide Addendum

PLT-03452, Rev. A.0

www.hidglobal.com/PLT-03455

• Scan the QR code or visit the link to see the multi-language electronic version of this document.
• Lisez le code QR ou suivez le lien pour consulter la version française de ce document.
• Escanee el código QR o visite el vínculo para consultar la versión en Español de este documento.
• Scannen Sie den QR-Code oder öffnen Sie den Link für die deutsche Version dieses Dokuments.
• Faça a leitura do código QR ou acesse o link da versão em português deste documento.
• Scansiona il codice QR o visita il link della versione Italiana di questo documento.
• Отсканируйте QR-код или пройдите по ссылке, чтобы получить версию этого документа на русском языке.
• 扫描 QR 码或访问此 文档的中文版本的链接。
• この文書の日本語版を表示するには、QR コードをスキャンするか、リンクを クリックします。
• QR 코드를 스캔하거나 링크를 방문하면 이 문서의 한국어 버전을 볼 수 있습니다.

IMPORTANT: Additional Initial Setup Steps Required for this Reader

The following additional steps are required before the Initial Setup - Functional Selections stage detailed in Section 2 of the iCLASS SE Biometric Reader User Guide (PLT-02550).

• 1. Disconnect power to the reader and then re-power.
• 2. Within 30 seconds of re-powering the reader, present configuration card SEC9X-CRD-E-P002 DOWNGRADE TO STANDARD READER ADMIN KEY before the Initial Setup stage detailed in Section 2 of the iCLASS SE Biometric Reader User Guide (PLT-02550). Hold the card to the reader until the reader stops beeping and the LED is solid red.
• 3. Complete the steps in Section 2 of the iCLASS SE Biometric Reader User Guide (PLT-02550).
• 4. Disconnect power to reader and then re-power.
• 5. Within 30 seconds of re-powering reader, present configuration card SEC9X-CRD-E-P000 UPGRADE TO ELITE READER ADMIN KEY (included in reader box). Hold the card to the reader until the reader stops beeping and the LED is solid red. The reader is now ready for Normal use.

Note: If the Initial Setup Reset is required to modify the reader configuration in the future, complete the following in place of the steps detailed in Section 2 of the iCLASS SE Biometric Reader User Guide (PLT-02550):

• 1. Disconnect power to the reader and then re-power.
• 2. Within 30 seconds of re-powering reader, present configuration card SE BIO Initial Setup Reset Card 1 (included in reader box). Hold the card to the reader until the reader stops beeping and the LED is solid red.
• 3. Disconnect power to the reader and then re-power.
• 4. Within 30 seconds of re-powering the reader, present configuration card SE BIO Initial Setup Reset Card 2 (included in reader box). Hold the card to the reader until the reader stops beeping and the LED is solid red.
• 5. Disconnect power to the reader and then re-power.
• 6. Within 30 seconds of re-powering the reader, present configuration card SEC9X-CRD-E-P002 DOWNGRADE TO STANDARD READER ADMIN KEY (included in reader box). Hold the card to the reader until the reader stops beeping and the LED is solid red.
• 7. Complete Initial Setup per Section 2 of the iCLASS SE Biometric Reader User Guide (PLT-02550).
• 8. Disconnect power to reader and then re-power.
• 9. Within 30 seconds of re-powering the reader, present configuration card SEC9X-CRD-E-P000 UPGRADE TO ELITE READER ADMIN KEY (included in reader box). Hold the card to the reader until the reader stops beeping and the LED is solid red. The reader is now ready for Normal use.

This Installation Guide is for informational purposes only. HID makes no warranties, expressed or implied, in this summary. Company, product names and data used in sample output are fictitious. Specifications are subject to change without notice.
