A key weapon in the fight against forgery

References

Our secure sewing threads are used in the passports of more than 30 countries, including:

• Argentina
• Azerbaijan
• Bolivia
• Brazil*
• Bulgaria
• Benin
• Cambodia
• Greece
• Hong-Kong*
• Ivory Coast
• Peru
• * Multicolored threads

HID Global's secure threads are dyed and assembled using specific, unique processes to enable the combination of fluorescent and non-fluorescent colored plies. These plies can be combined to give customized secure threads for easy passport authentication.

Characteristics

• Core-dyed for 100% color impregnation
• 100% polyamide for optimum strength
• Two, three, or four-ply threads available
• Custom visible and UV color sets
• 10 -year guarantee on all products
• Includes IR anti-stokes fluorescent threads

For each ply, a specific colour can be applied among:

Visible

• White (raw) -E
• Blue -B
• Red R
• Green V
• Yellow J
• Orange O
• Pink P
• Others upon trials

Fluorescent

• Dull / Blue / Green / Red
• Yellow/Orange/Pink
• Blue to Blue or Red
• Green to Blue, Green or Red
• Yellow to Blue, Green or Yellow
• Orange to Blue, Orange
• Pink to Pink or Red
• Purple to Pink
• Upon trials

For the best security choice, we strongly recommend threads containing one-ply (up to four-ply) in a visible white (raw) color and in a green or red color under UV light. Anti-stokes and fluorescent features can be combined, enhancing the security level, with a double control (UV and IR).

THREAD COLOR COMBINATIONS

Colors Under UV

	No Fluorescence	Light Blue	Blue	Dark Blue	Green	Green/ Yellow	Yellow	Orange	Pink	Red	Bi- Fluorescence	Anti- Stoke (IR)
Raw (White)	×	X	Х	Х	X		×	X	X	Х	×	X
Light Blue	×	X								Х		X
Dark Blue	×											X
Light Green	×	X			×					Х		X
Dark Green	X											X
Light Yellow	×	X								Х		X
Dark Yellow	×					Х	X					X
Light Orange	×	X										X
Dark Orange	×											X
Red/ Pink	×	×							Х	Х		X
Dark Red	×											X
Purple	×								Χ			X

TYPICAL PHYSICAL PROPERTIES

Ticket number (metric)	32/3	43/3	43/2
M/KG	9,800	13,000	19,660
Minimum Tensile Strength (g)	6,000	4,200	2,800
Fusion Point (°C)	260	260	260
Thickness (mm - +/- 10%)	0.56	0.48	0.37
Elongation (%)	20/30	25/35	23/33
Tex	102	70	51
Number of Plies (+/- 10%)	3	3	2

Reel Size	32/3	43/3	43/2
Outside Diameter (cm)	8	8	8
Length of the Core (cm)	14.5	14.5	14.5
Core Diameter (cm)	2.6	2.6	2.6
Weight (g)	~250	~250	~250
Length of Thread (m)	~2,450	~3,250	~4,900

Recommended Needles	32/3	43/3	43/2
Singer	19/21	14/16	12/14
Metric NR	120/130	90/100	80/90
Union Speciale	047/054	036/040	032/036

Colors Under Daylight
