HID OMNIKEY SE Plug ORM Commands – Extended

Guidelines for accessing PACS data using the Read/Write Terminal via OMNIKEY Reader Manager.

Please install the OMNIKEY Reader Manager https://apps.microsoft.com/detail/9p033t0q65zp

OMNIKEY® Reader Manager is an application designed to help with diagnosing, configuring, and updating OMNIKEY Gen3 readers. It currently supports the following products: l OMNIKEY SE Reader Core™. Refer to OMNIKEY SE Reader Core User Guide (PLT-06682) for more information. l OMNIKEY® SE Reader Plug, refer to OMNIKEY SE Plug User Guide (PLT-08263) for more information.

Below is an example flow for reading PACS data from a card. For additional commands or detailed information, please refer to the OMNIKEY SE Plug User Guide (PLT-08263).

• 1. Connect your reader.
• 2. Navigate to the "Read-Write Terminal" from the menu on the left.
• 3. Select your reader.
• 4. Enter the following commands:
  • Command 1: rfidScan

• Method: Post

• URI: card

• Payload: A26130006131A16131820001

A2 # map(2)
61 # text(1)
30 # "0" action:
00 # unsigned(0) 0x00 - scan
61 # text(1)
31 # "1" args:
A1 # map(1)
61 # text(1)
31 # "1" hf_proto_list:
82 # array(2)
00 # unsigned(0) 0x00 ECP
01 # unsigned(1) 0x01 ISO14443A

resp: A261300661314408FC671F

204 - SuccessChanged

A2 # map(2) 61 # text(1)

 30 # "0" type_sel:

06 # unsigned(6) 0x06 SEOS

61 # text(1) 31 # "1"

44 # bytes(4) csn:

08FC671F # "\b\xFCg\u001F" 08FC671F

• Command 2: rfidSelectAndAuthenticate

• Method: Post

• URI: card

• Payload: A1613001

A1 # map(1)

61 # text(1)

30 # "0" action:

01 # unsigned(1) 0x01 SELECT_AND_AUTH

response:

204 - SuccessChanged

• Command 3: rfidReadPacs

• Method: Post

• URI: card

• Payload: A1613006

A1 # map(1)

61 # text(1)

30 # "0" action:

06 # unsigned(6) 0x06 READ_PACS

response: A16130450680800080

204 – SuccessChanged

A1 # map(1)

61 # text(1)

30 # "0"

45 # bytes(5)

0680800080 # "\u0006\x80\x80\u0000\x80"

PACS Data: 0680800080
