HID OMNIKEY SE Plug ORM Commands

Guidelines for accessing PACS data using the Read/Write Terminal via OMNIKEY Reader Manager.

Please install the OMNIKEY Reader Manager https://apps.microsoft.com/detail/9p033t0q65zp

OMNIKEY® Reader Manager is an application designed to help with diagnosing, configuring, and updating OMNIKEY Gen3 readers. It currently supports the following products: l OMNIKEY SE Reader Core™. Refer to OMNIKEY SE Reader Core User Guide (PLT-06682) for more information. l OMNIKEY® SE Reader Plug, refer to OMNIKEY SE Plug User Guide (PLT-08263) for more information.

Below is an example flow for reading PACS data from a card. For additional commands or detailed information, please refer to the OMNIKEY SE Plug User Guide (PLT-08263).

• 1. Connect your reader.
• 2. Navigate to the "Read-Write Terminal" from the menu on the left.
• 3. Select your reader.
• 4. Enter the following commands:
  • Command 1: rfidScan

• Method: Post • URI: card

• Payload: A26130006131A16131820001

• Command 2: rfidSelectAndAuthenticate

• Method: Post • URI: card

• Payload: A1613001

• Command 3: rfidReadPacs

• Method: Post • URI: card

• Payload: A1613006
