BLE: Bluetooth Smart - 2.4 GHz
| Product Family | BEEKs™ | BluFi™ | |||||||
|---|---|---|---|---|---|---|---|---|---|
| Sub-family | Plus | Lite | CM v2/Industrial | Mini / Mini Tamper | Badge | Duress Badge | AC (US/EU/UK/AU) | DC (Battery) | DC (Plenum) |
| Description |
BLE beacon without sensors to be used for
Proximity Marketing, way-finding and/or real-time location (RTLS). |
Rugged BLE condition
monitoring beacon with embedded sensors to measure temperature and vibration of motorized equipment in manufacturing, coolers, escalators etc. |
Tiny BLE beacon with or
without tamper evidence functionality that raises an alert when beacon is removed. Supports real time location (RTLS). |
Beacon badge that can
be optionally combined with passive RFID card credentials for access control. Typically used for workplace optimization or emergency mustering. |
BLE badge holder, into which
a horizontally printed (RFID) ISO card can be inserted. Includes call button on the back that can raise an alert in the Bluzone console when in vicinity of a connected BluFi. |
BluFi acts as gateway between
BLE beacons and existing WiFi networks to enable cloud based remote management, location and beacon data collection. This model plugs into any standard A/C outlet and features an omnidirectional antenna. |
BluFi acts as gateway between
BLE beacons and existing WiFi networks to enable cloud based remote management, location and beacon data collection. This model features a rechargeable battery and directional antenna. Optional outdoor housing with solar panel available. |
BluFi DC Plenum is a
flame resistant, low voltage DC powered version that is designed to be installed on walls, ceilings or in the plenum, with an optional mounting kit. |
|
| Radio Type | Bluetooth Low Energy 4.1, 2.4 GHz ISM | Bluetooth Low Energy 4.1, Wifi 802.11 b/g/n | |||||||
| Bluetooth Sensitivity | -97dBm | -98dBm | |||||||
| Processor Type | ARM Cortex M3 and ARM Cortex M0 | ARM Cortex M4 and ARM Cortex M3 | |||||||
| Memory | 55KB Flash (512 KB optional) | 256KB Flash (100KB free for custom applications) | |||||||
| Protocols | Eddystone, iBeacon, sBeacon | Eddystone, iBeacon, sBeacon, WiFi | |||||||
| Power |
Up to 8 year battery life
Up to 5 year battery life |
Up to 3 year battery life | Up to 4 year battery life | 100-240 VAC, 50/60 Hz |
USB charger,
up to 24h battery life |
N/A | |||
| Dimensions |
2.41 x 1.46 in
(61.3 x 37.2 mm) |
2.36 × 0.85 in
(60 × 21 mm) |
1.3 x 0.3 in
(34.2 x 8.35 x 2.5 mm) |
2.14 × 3.39 x 0.10 in
(54 × 86 mm) |
2.5 in × 3.5 in x 0.19 in
(64 mm × 89 mm x 5 mm) |
2 × 1.5 x 1.5 in
(50 × 38 x 38 mm) |
3.4 X 3.2 X 1.2 in
(86.1 X 82.2 X 31.8 mm) |
||
| Affixation | 3M VHB adhesive sticker | Epoxy glue |
3M VHB adhesive sticker
with metal foil |
Clip | A/C power plug | Micro USB | USB Type A | ||
| Weight | 2.7 oz (76 g) | 1 oz (28 g) | 1.39 oz (37 g) | 0.24 oz (7 g) | 0.5 oz (14 g) | 0.85 oz (24 g) | 1.7 oz (48 g) | 9.3 oz (264 gr) | 4.13 oz (117 g) |
| Water resistance | IP67 | IP67 | |||||||
|
Operating
temperature |
-22° to +170° F
(-30° to +77° C) |
-13° F to +185° F
(-25° C to +85° C) |
-13° to +170° F
(-25° to +77° C) |
-4° to +170° F
(-20° to +77° C) |
-13° to +149° F
(-25° to +65° C) |
-4° to +158° F
(-20° to +70° C) |
|||
|
Withstands
Exposure To |
Water and UV Resistant | Water | Water, Flame UL-2043 | ||||||
| Compliant with |
FCC / CE
FCC / CE / JRF / IC |
FCC / CE |
FCC/CE/UL/FRE; BLE;
Wifi 2.4 GHz |
FCC/CE; BLE; Wifi 2.4 GHz | |||||
Advanced BLE Beacons with sensor technology and multiprotocol support
BEEKs™ Bluetooth Low-Energy (BLE) beacons are among the most advanced beacons in the industry. Being fully Apple iBeacon and Google Eddystone compatible, BEEKs beacons may be used for any standard beacon application that provides location based promotional services to smartphone users. When combined with HID Global's end-to-end IoT Services ecosystem, that includes BluFi™ BLE to WiFi gateways and the Bluzone™ cloud services, BEEKs can be centrally managed through the cloud to transfer messages, firmware updates and status information remotely. Their unique design allows BEEKs to broadcast reliably even in densely populated WiFi environments.
