Falcon Master Reinforcement Plan Metal Door Template 108489

IMPORTANT NOTES:

• • Choose correct hand of door.
• • Reinforcements to be 4Z\x" minimum wide or full width of stile.
• • Reinforcement on outside of door required only if outside trim is used.
• • Reinforcement to be adequate for the drilling and tapping of machine screws. • Refer to templates listed for additional cut-outs, tapped hole requirements,
• and other specific reinforcement. • Tap holes for hinge stile mounting when applying device.

• Shields are recommended on mortise lock installations to protect the lock,

device and trim from the door insulation.

TEMPLATE

T-0100-b
