Falcon (F)XX-R Series Rim Device with FSA or FSE Feature Wood Door Template 108969

(F)XX-R Series Rim Device with FSA or FSE Feature

Knob, Lever and Thumbpiece Trim, Wood Door, LHR Shown, RHR Opposite

• For outside trim, see trim template for door preparation.

• For sexbolt preparation, refer to Template W-4014.

TEMPLATE

W-5001-a
