FS23M-Pricesheet

Open the original PDF document

View PDF

SPACESAVER® Mortise Bolt Locks Fit 1-3/4" Frames AK LIST Distributor

Discount Code

Dimensions: 8"L x 1-1/2"W x 1-5/8"D

FS/1090/1490 Dual Voltage Coil: 900/450 mA @ 12/24 VDC 1290/2490 Dual Voltage Coil: 900/450 mA @ 12/24 VDC

3773-0324:001

Auxiliary Locks

UL10C Positive Pressure Compliant UBC Classified in accordance with Uniform Building Code standard 7-2 "Fire Test for Door Assemblies"

SPECIFY FINISH Add to List
V 628 Aluminum Finish (standard) N/C
Y 335 Black 41.00
Plated Architectural Finishes
Special order - no cancellations, no return
C 605 Bright Brass 87.00
D 606 Dull Brass 87.00 P 625 Bright Chrome 87.00
F 611 Bright Bronze 87.00 Q 626 Dull Chrome 87.00
G 612 Satin Bronze 87.00 U 630 Stainless Steel 87.00
H 613 Oil Rubbed Bronze 87.00
OPTIONS Add to List
D Door position sensor, SPDT 61.00
B Bolt position sensor, SPDT 61.00

SPACESAVER® Mortise Bolt Locks FOR WOOD FRAMES AK LIST Distributor Discount Code

SPECIFY MODEL List
1091AIWD Failsafe 12/24VDC, with 8-1/2" x 1-1/2" x 1/8" faceplate 475.00
1190AWDU Failsafe Heavy Duty 24VDC, Stainless Steel Finish ONLY 547.00
1291AHWD Failsecure 12/24VDC, with 9" x 1-1/2" x 1/8" faceplate 547.00

SPECIFY FINISH Add to List

V 628 Aluminum Finish (standard) N/C
Y 335 Black 41.00
Plated Architectural Finishes
Special order - no cancellations, no return
C 605 Bright Brass 87.00
D 606 Dull Brass 87.00 P 625 Bright Chrome 87.00
F 611 Bright Bronze 87.00 Q 626 Dull Chrome 87.00
G 612 Satin Bronze 87.00 U 630 Stainless Steel 87.00
H 613 Oil Rubbed Bronze 87.00
OPTIONS Add to List
D Door position sensor, SPDT 61.00
B Bolt position sensor, SPDT 61.00
