PRICE LIST
July 1, 2018
TABLE OF CONTENTS
| Series 3690 | 2 |
| Series FL3690 | 2 |
| Series 3790 | 3 |
| Series 3190 | 3 |
| Series 8860 | 4 |
| Series RM370 | 4 |
| Series L3 | 5 |
| Continuous Gear Hinges | 5 |
| Retrofit Kits | 6 |
| Accessory Items | 6 |
| Terms and Conditions | 7 |
www.FirstChoiceBuildingProducts.com
sales@FirstChoiceBuildingProducts.com P: (800) 793-4544 | F: (800) 867-5016
SERIES 3690
VERTICAL ROD DEVICE
PART NUMBERING
SAMPLE NUMBER
A/36/B/C-D
369236-CL
BASE PRICE $440.00
SERIES FL3690
IMPACT RATED
PART NUMBERING
SAMPLE NUMBER
A/FL36/B/C-D
FL369236-CL
BASE PRICE $493.00
| (A) ACCESSORIES | ADD |
|---|---|
| MEL = Electric Latch Retraction by Motor Drive | $996.00 |
| EL = Electric Latch Retraction by Solenoid | $498.00 |
| SW = Signal Switch | $267.00 |
| CD = Interior Dogging by Key Cylinder | $167.00 |
| AL = Alarm Function | $410.00 |
| CDAL = Alarm Function with Cylinder Off/On | $577.00 |
|
D = Dummy (Inactive) Device
Total Price |
$413.00 |
| (B) FUNCTION | ADD |
| 90 = Exit Only, No Trim | Incl. |
| 91 = With 1" Round Offset Pull (10" centers) | $128.00 |
| 92 = Prepped for exterior key cylinder, no cylinder | $45.00 |
| 93 = Prepped for exterior key cylinder with cylinder | $95.00 |
| (C) SIZE | ADD |
| 36 = 36" D O Width (Standard) | Incl. |
| 30 = 30" D O Width | $20.00 |
| 42 = 42" D O Width | $20.00 |
| 48 = 48" D O Width | $20.00 |
| XX = Special Width | $39.00 |
| XX (MEL & EL) = Special Width | $83.00 |
| 7'0" D O Height (Standard) | Incl. |
| XX = Special Height to 120" Tall | $58.00 |
| (D) FINISH | ADD |
| CL = Clear Anodized | Incl. |
| BR = Dark Bronze Anodized | Incl. |
| BL = Black Anodized | Incl. |
| SP = Special (Anodized or Painted Only) | Consult |
| Factory | |
| SPECIAL LATCHES | ADD |
| H = Hex Bottom | Incl. |
| 3690P = Pullman Style Bottom | $65.00 |
| P3690 = Pullman Style Top | $167.00 |
| (A) ACCESSORIES | ADD |
|---|---|
| MEL = Electric Latch Retraction by Motor Drive | $1,039.00 |
| SW = Signal Switch | $267.00 |
| CD = Interior Dogging by Key Cylinder | $167.00 |
| (B) FUNCTION | ADD |
| 90 = Exit Only, No Trim | Incl. |
| 91 = With 1" Round Offset Pull (10" centers) | $128.00 |
| 92 = Prepped for exterior key cylinder, no cylinder | $45.00 |
| 93 = Prepped for exterior key cylinder with cylinder | $95.00 |
| (C) SIZE | ADD |
| 36 = 36" D O Width (Standard) | Incl. |
| 30 = 30" D O Width | $27.00 |
| 42 = 42" D O Width | $27.00 |
| 48 = 48" D O Width | $27.00 |
| XX = Special Width | $83.00 |
| 7'0" D O Height (Standard) | Incl. |
| XX = Special Height to 98" Tall | $58.00 |
| H2 = 2-3/8" Thick Zone 4 Impact | $53.00 |
| (D) FINISH | ADD |
| CL = Clear Anodized | Incl. |
| BR = Dark Bronze Anodized | Incl. |
| BL = Black Anodized | Incl. |
| SP = Special (Anodized or Painted Only) |
Consult
Factory |
SERIES 3790
RIM DEVICE
PART NUMBERING A/36/B/C-D SAMPLE NUMBER 379236-CL
BASE PRICE $401.00
SERIES 3190
MID RAIL MOUNTED CVR DEVICE
PART NUMBERING A/36/B/C-D SAMPLE NUMBER 319236-CL
BASE PRICE $635.00
| (A) ACCESSORIES | ADD |
|---|---|
| MEL = Electric Latch Retraction by Motor Drive | $999.00 |
| EL = Electric Latch Retraction by Solenoid | $499.00 |
| SW = Signal Switch | $267.00 |
| CD = Interior Dogging by Key Cylinder | $167.00 |
| AL = Alarm Function | $410.00 |
| CDAL = Alarm Function with Cylinder Off/On | $577.00 |
| (B) FUNCTION | ADD |
| 90 = Exit Only, No Trim | Incl. |
| 91 = With 1" Round Offset Pull (10" centers) | $128.00 |
| 92 = Prepped for exterior key cylinder, no cylinder | $45.00 |
| 93 = Prepped for exterior key cylinder with cylinder | $95.00 |
| (C) SIZE | ADD |
| 36 = 36" D O Width (Standard) | Incl. |
| 30 = 30" D O Width | $20.00 |
| 42 = 42" D O Width | $20.00 |
| 48 = 48" D O Width | $20.00 |
| XX = Special Width | $39.00 |
| XX (MEL & EL) = Special Width | $83.00 |
| (D) FINISH | ADD |
| CL = Clear Anodized | Incl. |
| BR = Dark Bronze Anodized | Incl. |
| BL = Black Anodized | Incl. |
| SP = Special (Anodized or Painted Only) |
Consult
Factory |
| (A) ACCESSORIES | ADD |
|---|---|
| MEL = Electric Latch Retraction by Motor Drive | $996.00 |
| EL = Electric Latch Retraction by Solenoid | $498.00 |
| SW = Signal Switch | $267.00 |
|
D = Dummy (Inactive) Device
Total Price Includes MP011 Mounting Kit for Inactive Device |
$100.00 |
|
FL = Impact Rated
(Consult factory for additional information) |
$106.00 |
| (B) FUNCTION | ADD |
| 90 = Exit Only, No Trim | Incl. |
| 92 = Prepped for exterior key cylinder, no cylinder | $109.00 |
| 93 = Prepped for exterior key cylinder with cylinder | $160.00 |
| (C) SIZE | ADD |
|
36 = 36"" D O Width (Standard)
Muntin length = 34" Filler Bar Length = 12" |
Incl. |
| XX = Special Width | $50.00 |
| XX (MEL & EL) = Special Width | $100.00 |
| 7'0" D O Height (Standard) | Incl. |
| XX = Special Height to 96" Tall | $58.00 |
| (D) FINISH | ADD |
| CL = Clear Anodized | Incl. |
| BR = Dark Bronze Anodized | Incl. |
| BL = Black Anodized | Incl. |
| SP = Special (Anodized or Painted Only) |
Consult
Factory |
| SPECIAL LATCHES | ADD |
| H = Hex Bottom | Incl. |
| 3190P = Pullman Style Bottom | $65.00 |
| P3190 = Pullman Style Top | $167.00 |
| Muntin Material - 48" Clear or Dark Bronze | $64.00 |
| Push Bar / Filler Bar Material - 48" Long | $64.00 |
SERIES 8860
MORTISE
PART NUMBERING SAMPLE NUMBER
8860/A/B-C/D/E/F 886036CD-CLR02S1
BASE PRICE $528.00
| (A) SIZE | ADD |
|---|---|
| 36 = D O Width 36" - 30" (Standard) | Incl. |
| 42 = D O Width 42" - 36" | $20.00 |
| 48 = D O Width 48" - 42" | $20.00 |
| XX = Special Width | $39.00 |
| (B) ACCESSORIES | ADD |
| MEL = Electric Latch Retraction by Motor Drive | $996.00 |
| SW = Signal Switch | $267.00 |
| CD = Interior Dogging by Key Cylinder | $167.00 |
| AL = Alarm Function | $410.00 |
| D = Dummy (Inactive) Device | $413.00 |
| (C) FINISH | ADD |
| CL = Clear Anodized | Incl. |
| BR = Dark Bronze Anodized | Incl. |
| BL = Black Anodized | Incl. |
| SP = Special Anodized or Painted Finishes |
Consult
Factory |
| (D) HANDING | ADD |
| R = Right Hand | N/C |
| L = Left Hand | N/C |
| (E) BACKSET OF LOCK BODY | ADD |
| 01 = 31/32" | $21.00 |
| 02 = 1-1/8" | Incl. |
| 03 = 1-1/2" | $21.00 |
| (F) STRIKE TYPE | ADD |
| S1 = 2" Standard | Incl. |
| S2 = 3" Extended | $11.00 |
| S3 = 4" Tall Strike | $11.00 |
| With Key Cylinder = 8863xxxx-xxxxxxx | $51.00 |
SERIES RM370
MULLIONS
PART NUMBERING SAMPLE NUMBER
RM370-A/B RM370-8CL
BASE PRICE $623.00
| (A) SIZE | ADD |
|---|---|
| 7 = 7'0" D O Height | Incl. |
| 8 = 8'0" D O Height | Incl. |
| 9 = 9'0" D O Height | Incl. |
| XX = Special Door Height | $689.00 |
| (B) FINISH | ADD |
| CL = Clear | Incl. |
| BR = Dark Bronze | Incl. |
| SP = Special Anodized or Painted Finish |
Consult
Factory |
| SPECIAL PREP | ADD |
|
SP1 = No Strikes or Strike Prep; With Security Clips
and Clip Prep |
$30.00 |
|
SP2 = No Strikes or Strike Prep and No Security Clips
or Clip Prep |
$20.00 |
| KRM = Keyed Removable Mullion (CL or BR) | $127.00 |
|
The following preps enable installation of a surface mounted
electric strike. The exit device mounting location will have to be modified to provide proper clearance. |
|
|
RM370E = Single Side Prep For Electric Strike (no
strike) (Handing Required: L = Left Hand Swing Out / R = Right Hand Swing Out) |
$120.00 |
|
RM370E1 = Dual Side Prep For Electric Strike
(No Strike) |
$170.00 |
|
RM370E2 = Single Side Prep For Electric Strike With
One Strike (Handing Required: L = Left Hand Swing Out / R = Right Hand Swing Out) |
$650.00 |
SERIES L3
LEVER TRIM
PART NUMBERING SAMPLE NUMBER
L3ABB-CC-DD L3710-M1-28
BASE PRICE $435.00
| (A) EXIT DEVICE TYPE | ADD |
|---|---|
| L36 = 3690 Concealed Vertical Rod | Incl. |
| L37 = 3790 Rim Latching | Incl. |
| (BB) HANDING | ADD |
| 10 = LHRB (For Right Hand Swing Out) | N/C |
| 20 = RHRB (For Left Hand Swing Out) | N/C |
| 13 = LHRB With Key Cylinder (For Right Hand Swing Out) | $51.00 |
| 23 = RHRB With Key Cylinder (For Left Hand Swing Out) | $51.00 |
| (CC) LOCKING FUNCTION | ADD |
| M0 = Inactive (Dummy) | Incl. |
| M1 = Night Latch (Key always required) | Incl. |
| M2 = Passage (Always active) | Incl. |
|
M3 = Hold Open (Key required only for setting and
removing Hold Back) |
Incl. |
| E1 = Electric (Lever handle released by signal or key) | $65.00 |
| (DD) FINISH | ADD |
| 28 = Clear Anodized | Incl. |
| 13 = Dark Bronze | Incl. |
CONTINUOUS GEAR HINGES
| FULLY CONCEALED | ||||
|---|---|---|---|---|
| FC110 | FC111 | FC240 | ||
| >No Inset | >1/8" Inset | >3/32" Inset | ||
| >Door Lip | ||||
| Protector | ||||
| 83" | Clear | $123.00 | $123.00 | $123.00 |
| Dark Bronze | $157.00 | $157.00 | $157.00 | |
| Black | $180.00 | $180.00 | $180.00 | |
| 95" | Clear | $160.00 | $160.00 | $160.00 |
| Dark Bronze | $204.00 | $204.00 | $204.00 | |
| Black | $235.00 | $235.00 | $235.00 | |
| 120" | Clear | $233.00 | $233.00 | $233.00 |
| Dark Bronze | $298.00 | $298.00 | $298.00 | |
| Black | $342.00 | $342.00 | $342.00 | |
HALF MORTISE
| FC530 | ||
|---|---|---|
| >3/32" Inset | ||
| 83" | Clear | $192.00 |
| Dark Bronze | $245.00 | |
| Black | $282.00 | |
| 95" | Clear | $249.00 |
| Dark Bronze | $319.00 | |
| Black | $367.00 | |
| 120" | Clear | $364.00 |
| Dark Bronze | $466.00 | |
| Black | $536.00 |
FULL MORTISE
| FC570 | ||
|---|---|---|
| >1/16" Inset | ||
| >Narrow Frame | ||
| 83" | Clear | $190.00 |
| Dark Bronze | $243 .00 | |
| Black | $279.00 | |
| 95" | Clear | $246.00 |
| Dark Bronze | $315.00 | |
| Black | $363.00 | |
| 120" | Clear | $361 |
| Dark Bronze | $460 | |
| Black | $529 |
| OPTIONS | |
|---|---|
| TW4 = Through Wire [4 wire] for concealed electrification | $100.00 |
| TW4-R = Removable Through Wire [4 wire] for | $120.00 |
concealed electrification
PT = Prep for EPT300 Power Transfer $150.00
RETROFIT KITS
ACCESSORY ITEMS
| ELECTRIC LATCH RETRACTION KITS | |
|---|---|
|
MEL3000-1 = Electric Latch Retraction by Motor
(24v DC x 1 Amp Draw) Suitable for 3690 CVR or 3790 Rim Latching Exit Devices |
$996.00 |
|
FLMEL3000-1 = Electric Latch Retraction by Motor For
Impact Devices (24v DC x 1 Amp Draw) Suitable for FL3690 CVR Exit Devices |
$996.00 |
| Matching 1 amp Power Supply | |
| PSMEL1500 Single Door 1 Amp Power Supply | $297.00 |
|
EL3000-1 = Electric Latch Retraction by Solenoid
(2vDC x 16 Amp Draw on Inrush; 1 amp Holding) Suitable for 3690 CVR and 3790 Rim Latching Exit Devices, Not available for Impact Doors |
$498.00 |
| Matching 16 amp Power Supply | |
| PSEL1500 Single Door 16 Amp Power Supply | $657.00 |
| PSEL3000-2 Two Door 16 Amp Power Supply | $1,102.00 |
| INTERIOR CYLINDER DOGGING KITS | |
|
CD3000 = Interior Key Dogging Assembly Only
(Clear or Dark Bronze) |
$267.00 |
|
CD3000UK = Interior Key Dogging Assembly
With Machined Push Bar |
$363.00 |
| -36CL = 36" D O in Clear Anodized | Incl. |
| -36BR = 36" D O in Dark Bronze Anodized | Incl. |
| -42CL = 42" D O in Clear Anodized | Incl. |
| -42BR = 42" D O in Dark Bronze Anodized | Incl. |
| -48CL = 48" D O in Clear Anodized | Incl. |
| -48BR = 48" D O in Dark Bronze Anodized | Incl. |
| -XX = Special Size | $394.00 |
| ALARM KIT | |
| AL36 = Board Mounted Alarm With Decal | $346.00 |
| SIGNAL SWITCH KITS | |
|
SX9700 = Board Mounted Signal Switch - NO/NC
Circuit (Reads Position of Push Bar) |
$223.00 |
|
SW300-2CA = Activating Bracket Mounted Signal
Switch - NO/NC Circuit (Reads Position of Push Bar) |
$223.00 |
| TRIM | |
|---|---|
| Key Cylinders | |
| 9052 - Rim Type | $51.00 |
| -CL = Clear | Incl. |
| -BR = Dark Bronze | Incl. |
| -BL = Black | Incl. |
| MM100 Mortise | $51.00 |
| -CL = Clear | Incl. |
| -BR = Dark Bronze | Incl. |
| 9052-T Thumb Turn Rim Type | $61.00 |
| -CL = Clear | Incl. |
| -BR = Dark Bronze | Incl. |
| Offset Pulls | |
| M950 | $128.00 |
| -CL = Clear Anodized | Incl. |
| -BR = Dark Bronze | Incl. |
| ELECTRIC ACCESSORIES | |
| Power Transfers | |
| EPT300 Fully Concealed Power Transfer | $156.00 |
| EMT300 Surface Mounted Loop Style Power Transfer | $89.00 |
| -CL= Painted to Match Clear | Incl. |
| -BR = Painted To Match Dark Bronze | Incl. |
| Electric Strikes | |
| HS94 Electric Strike for 3790 Rim Latching Device | $795.00 |
| -CL = Clear | Incl. |
| -BR = Dark Bronze | $50.00 |
TERMS AND CONDITIONS
1. CONTACT US
• By phone: 1 (800) 793-4544 • By fax: 1 (800) 867-5016
• By e-mail: sales@firstchoicebuildingproducts.com
2. PRICES
- List prices are effective on the date appearing on the cover and are subject to change without notice.
- Prices shown herein are subject to discounts in effect at the time orders are acknowledged in writing.
- Errors or omissions are subject to correction.
- All quoted jobs must clearly reference the estimate number on purchase orders in order to receive the correct quoted price.
3. FREIGHT
- All orders are F.O.B. factory
- Prepaid freight will be shipped using the carrier of our choice when a specific carrier is not referenced.
4. TERMS
• All terms must be negotiated directly with First Choice Building Products, Inc.
5. ORDER ENTRY
- All orders received will be entered and acknowledged within 24 hours (orders sent Friday may take until the following Monday to be acknowledged).
- If your acknowledgment is not received then please assume we did not receive your order and resend it / call us.
- The acknowledgment will include the "Due Date" which is the date we will ship your order from our factory.
6. Minimum Orders
• No minimum order requirements.
7. Returns
- All Returned Goods Authorizations (RGAs) must be requested directly from First Choice Building Products, Inc.
- All return shipments must reference a valid RGA number.
- Freight costs to return goods are not paid for by First Choice Building Products, Inc. unless previously authorized.
- All goods must be returned to First Choice Building Products, Inc. within 60 days of the RGA authorization date in the same condition as the original order left our factory (less they be subjected to reevaluation of stocking fee).
- For all RGAs involving a request for a replacement, First Choice will invoice the replacement in full and the customer will be held responsible for the cost. Once the RGA item/s are received and inspected by First Choice the appropriate credit will be issued.
8. CLAIMS
• All claims as to errors or shortages must be reported in writing with 15 days from receipt of order.
9. PRODUCTS CHANGES
• First Choice Building Products, Inc. reserves the right to makes changes or improvements in the design, material, parts or specifications; as well as to discontinue products at any time.
10. LIMITED WARRANTY
- First Choice warrants that products manufactured by us will be free of defects in material and workmanship for a period of two year s from date of invoice.
- First Choice shall not be liable for any repairs, replacements, or adjustments to the products or any costs of labor performed by the purchaser or others without First Choice Building Products, Inc.'s prior written approval.
- First Choice makes no other warranty or representation of any kind whatsoever, expressed or implied, except that of title, and all other implied warranties of merchantability and fitness for a particular purpose, are hereby disclaimed.
- See website for specific warranty details.
www.FirstChoiceBuildingProducts.com
sales@FirstChoiceBuildingProducts.com P: (800) 793-4544 | F: (800) 867-5016
