Door Thickness Specifications

Passage

Standard Door Thickness: 1 1/4" - 1 3/4"

Standard Components:

• Inside Passage Half Spindle
• 3/4" Wood Screws
• 1 1/2" and/or 2" Mounting Screws
• Full-Lip Strike Plate

Extended Door Thickness: 1 3/4" - 2 1/4"

Extended Components:

• Long Inside Passage Half Spindle
• 3/4" Wood Screws
• 2 1/2" Mounting Screws
• Extended Full-Lip Strike Plate

Extended Door Thickness: 2 1/4" - 3"

Extended Components:

• Extra Long Inside Passage Half Spindle
• 3/4" Wood Screws
• 3" Mounting Screws
• Extended Full-Lip Strike Plate

Privacy

Standard Door Thickness: 1 1/4" - 1 3/4"

Standard Components:

• Regular Tailpiece
• Inside Passage Half Spindle
• 3/4" Wood Screws
• 1 1/2" and/or 2" Mounting Screws
• Full-Lip Strike Plate
• Deadbolt Strike Plate

Extended Door Thickness: 1 3/4" - 2 1/4"

Extended Components:

• Long Single Cylinder Tailpiece
• Long Inside Passage Half Spindle
• 3/4" Wood Screws
• 2 1/2" Mounting Screws
• Extended Full-Lip Strike Plate
• Deadbolt Strike Plate

Extended Door Thickness: 2 1/4" - 3"

Extended Components:

• Extra Long Single Cylinder Tailpiece
• Extra Long Inside Passage Half Spindle
• 3/4" Wood Screws
• 3" Mounting Screws
• Extended Full-Lip Strike Plate
• Deadbolt Strike Plate

Dummy

Standard Door Thickness: 1 1/4" - 1 3/4"

Standard Components:

• 1 1/2" and/or 2" Mounting Screws

Extended Door Thickness: 1 3/4" - 2 1/4"

Extended Components:

• 2 1/2" Mounting Screws

Extended Door Thickness: 2 1/4" - 3"

Extended Components:

• 3" Mounting Screws
