Emtek Contemporary Specifications

Open the original PDF document

View PDF

COMTEMPORARY CONTEMPORARY

Cabinet Knobs & Pulls Technical Specifications

Globe Knob

( Back Plate

Product Code Dimension(D) Projection(P) Base Diameter(B) Stem Diameter(S)

86152 1 1/8" 1 1/2" 1" 1/2"

Finger Pull

Product Code Dimension(D) Projection(P) Width(W)

7/8" 1" 86150 86151

1" 1 1/4"

5/8" 5/8"

Ring Knob

( 2 Screws are Included )

C-to-C Product Code Dimension Projection(P) Width(W)

1" 86270

1 1/4" 3/8"

Cone Knob

Product Code Dimension(D) Projection(P) Base Diameter(B)

1" 1 1/8" 86261 86262

1 1/8" 1 3/8"

1/2" 5/8"

Metric Knob

1 1/4" 1 1/8" 86268 Product Code Dimension(D) Projection(P)

1 1/8" 1 3/8" 86269

Trail Knob

Product Code Dimension(D) Projection(P) Base(B) Width(W)

86271 2" 1 3/8" 3/8" 5/8"

Cabinet Knobs & Pulls Technical Specifications

Arch Pull Overall Length Product Code Dimension
C-to-C 		Overall Length Projection(P)
(P)
Center-to-Center 		86153
86154
86155
86251 		3"
3 1/2"
4"
6" 		4 3/4"
5 1/8"
5 5/8"
8 3/4" 		1 1/8"
1 1/8"
1 1/8"
1 1/4"
Orbit Pull Product Code Dimension
C-to-C 		Overall Length Projection(P)
Overall Length
(P)
Center-to-Center 		86256
86257
86258
86259
86260 		3"
3 1/2"
4"
6"
10" 		3 3/8"
3 7/8"
4 3/8"
6 3/8"
10 3/8" 		1"
1"
1"
1"
1"

CONTEMPORARY

COMTEMPORARY Cabinet Knobs & Pulls Technical Specifications

Product Code Overall Length Dimension
C-to-C 		Projection(P) Base Diameter(B) Bar Width(W)
86357 2" N/A 1 1/4" 3/8" 1/2"
86358 5" 3" 1 1/4" 3/8" 1/2"
86359 5 ½" 3 ½" 1 1/4" 3/8" 1/2"
86360 6 1/2" 4" 1 1/4" 3/8" 1/2"
86361 7 ½" 5" 1 1/4" 3/8" 1/2"
86362 8 1/2" 6" 1 1/4" 3/8" 1/2"
86363 10 ½" 8" 1 1/4" 3/8" 1/2"
86364 12 ½" 10" 1 1/4" 3/8" 1/2"
86365 14 ½" 12" 1 1/4" 3/8" 1/2"
86366 18 ½" 16" 1 1/4" 3/8" 1/2"
86367 26 ½" 24" 1 1/4" 3/8" 1/2"
Also available in Appliance Pulls:
86351 15 1⁄4" 12" 2" 5/8" 3/4"
86352 21 1/4" 18" 2" 5/8" 3/4"
| (2") · Overall Length
W (P) (P) (P) (P) (P) (P) (P) (P) (P) (P)
Brass Bar Kno ob (86357) Brass Bar Pull

TS-CH REV19 10/17/19
