Technology that saves lives
Sealed Lead-Acid Batteries
Overview
Rechargeable sealed lead-acid batteries are ideal for use as a secondary (standby) power source as defined by NFPA 72. Their low maintenance and high energy density make them ideal for fire alarm signaling applications.
Standard Features
- Rechargeable
- Non-spillable
- Non-hazardous
- Low maintenance
- High energy density
Application
When multiple power supplies are provided, each power supply's battery requirements should be calculated individually. Consult the specific system manual to determine battery capacity requirements.
Safety Information
Due to a battery's low internal resistance and high power density, high levels of short circuit current can develop across battery terminals. Put on protective eye covering and remove all jewelry before working on batteries. Do not rest tools or cables on the battery, and only use insulated tools. Follow all manufacturers installation instructions and diagrams when installing or maintaining batteries.
Technology that saves lives
Contact us...
Email: kidde.fire@fs.utc.com Web: Kidde.com/EngineeredSystems
Kidde is a UTC brand. 1016 Corporate Park Drive Mebane, NC 27302
© 2016 United Technologies Corporation. All rights reserved.
Specifications
| Case Material | ABS Thermoplastic | |
|---|---|---|
| Regulatory Information | DOT Class 60, Batteries, non-hazardous, non-spillable | |
| Operating Environment | 32° F to 120° F (0° C to 49° C) 0 to 93% RH, Non-condensing | |
Ordering Information
| Catalog Number | Description | Shipping Weight, lb (kg) |
|---|---|---|
| 12V1A2 | 1.2 Ah Sealed Lead Acid Battery - 12 Vdc | 1.25 (0.57) |
| 12V4A | 4.5 Ah Sealed Lead Acid Battery - 12 Vdc | 5 (2.27) |
| 12V6A5 | 7.2 Ah Sealed Lead Acid Battery - 12 Vdc | 6 (2.72) |
| 6V8A | 8 Ah Sealed Lead Acid Battery - 6 Vdc | 4 (1.81) |
| 6V10A | 12 Ah Sealed Lead Acid Battery - 6 Vdc | 5 (2.27) |
| 12V10A | 11 Ah Sealed Lead Acid Battery - 12 Vdc | 10 (4.45) |
| 12V17A | 18 Ah Sealed Lead Acid Battery - 12 Vdc | 13 (5.90) |
| 12V24A | 26 Ah Sealed Lead Acid Battery - 12 Vdc | 20 (9.07) |
| 12V40A | 40 Ah Sealed Lead Acid Battery - 12 Vdc | 32 (14.51) |
| 12V50A | 50 Ah Sealed Lead Acid Battery - 12 Vdc | 40 (18.14) |
| 12V65A | 65 Ah Sealed Lead Acid Battery - 12 Vdc | 49 (22.23) |
