Edwards Signaling 103 Series Flyer Catalog

Changing status. Multiple processes. Adverse locations. Adapting to the diverse needs in your signaling environment has always been a tough job. But not with the Edwards Chameleon.

The Chameleon 103 Series combines three different LED visual signals in one compact housing. Three colors. Two operating modes. One light. The Chameleon eliminates the need for multiple lights in low profile, multistatus indication, reducing installation time and costs.

And with its NEMA 4X rating, the Chameleon is able to operate in the harshest of environments.

The 103I features a unique on-board processor with an internal jumper, which allows the single unit to

function as either a steady or flashing visual signal. Any one, or all three lights, can easily be activated by either a PLC or contact closure. The first light activated will illuminate either steady or flashing. When a second light is activated, the Chameleon cycles between the two colors, and activation of a third light causes it to cycle between all three colors: red, amber, and green or red, amber, and blue.

The 103 model performs similar to the 103I, but all signal operation in the 103 is controlled directly through a PLC's ladder logic, rather than through the Chameleon's internal processor.

You're already accustomed to innovative Signal SolutionsSM from Edwards. Now we have one answer for all your low-profile multi-status signaling needs.

Models cycle between three colors – red, green & amber or red, blue & amber

®

90 Fieldstone Court Cheshire, CT 06410-1212 Phone (203) 699-3300 Fax-on-Demand (203) 699-3361 www.edwards-signals.com
