The European Certification Body GmbH accredited according to EN 45011 awards to
Kaba Mas LLC
749 W. Short Street, Lexington, KY 40508 / US
the right to carry the ECB • S certification mark for
High security locks of class B according to EN 1300:2004+A1:2011 and ECB•S C10 (Series LA GARD 3390V – Types 3390VZK and 3390VZN – mechanical code lock ) (see Annex)
Certificate Number 538102/HSL09-07A
This certificate will expire on
23 March 2018
(valid from 24 March 2014)
24 March 2014
Frankfurt am Main
DAKKS Deutsche Akkreditierungsstelle D-ZE-11146-01-01
Dr. Markus Heering
Certification Body
European Certification Body GmbH Lyoner Straße 18 • 60528 Frankfurt am Main • Germany
Kaba Mas LLC, Lexington / US
| SURVEY - | Technical | documentation | (Series LA GAI | RD 3390V) |
|---|---|---|---|---|
| TECHNICAL DOCUMENTATION | FILE NAME OF DOCUMENT | DATE |
NUMBER
OF PAGES |
|---|---|---|---|
| Explosion drawing | 3370T000-00-00 | 10.05.2007 | 1 |
| Bill of material |
3390VZN03ZZZN2B
VdS BOM 3390T000-03.xls |
05.06.2008 | 1 |
| Bill of material |
3390VZK00ZZZN2B
BOM 3390FT00-00, 6-13-08.xls |
13.06.2008 | 1 |
| with the parts drawings listed in the bill of material | |||
| Lock case | 3371 | 08.01.2008 | |
| Lock cover | 3372 | 11.12.2007 | 1 |
| Cam | 3374 | 11.12.2007 | 1 |
| Arresting pin | 3378 | 12.03.2008 | 1 |
| Cover plate | 705002 | 28.02.2008 | 1 |
| Bolt switch | 1945 | 14.07.2008 | 1 |
| Anti pick lever | 3377 | 29.09.2009 | 1 |
| Spring anti pick lever | 3379 | 22.10.2009 | 1 |
| Montageanleitung |
Mech.
Kombinationsschlösser LA GARD 1947/1985/3330/3332/3370/ 3390 |
09.02.2009 | 12 |
| Installation manual | 709.058 Rev F 07/11 | 07/11 | 2 |
| Bedienungsanleitung |
Mechanische
Kombinationsschlösser LA GARD 1985/3330/3332/3370/3390 |
07.07.2008 | 2 |
| Users instruction bolt switch | 736.098v1 | 09/08 | 1 |
| Operating and changing instructions | 723.069 Rev. B | 01/11 | 2 |
| continued or | n page 2 |
continued on page 2
Kaba Mas LLC, Lexington / US
SURVEY - Technical documentation (Series LA GARD 3390V)
| TECHNICAL DOCUMENTATION | FILE NAME OF DOCUMENT | DATE |
NUMBER
OF PAGES |
|---|---|---|---|
| Test reports of VdS laboratory for security | STM 05 805 | 25.11.2005 | |
| 1. Nachtrag zu STM 05 805 | 21.11.2008 | ||
| Technical documentation according section 6 of test report No. STM 05 805 and the 1. Addendum | 12 | ||
| IOTE When mounting the lock installation ins | truction has to be followed |
