View PDFRescue Hardware
Double-Lipped Strikes
Standard Features
- Allows door to open in both directions without damaging the frame
- Door to be mounted on center hung pivot set ABH 0327, 0127, 0128 or 0370 (see pivot section for details)
- For use on 1-¾" thick doors center hung or ⅛" inset
- Can be used in conjunction with ABH 4590 Rescue Stop (see page J-2 for details)
- Cut-out is standard for cylindrical latches. Custom units available for mortise locks (see pages J-5 to J-9)
- Standard models are for 5-¾" and 6-¾" frame size. Custom frame sizes available (see pages J-4 to J-9)
- Supplied with 8-32 x ⅜" undercut machine screws
- .074" thick stainless steel material
- Available in US32D, US32, US10B, US10, US3 and US4
- Meets and/or exceeds ANSI Standard A1882
Options
• SEC - Pin-in socket security fasteners
Center Hung Door - Cylindrical Latch DS4510 - 5-¾" Frame DS4520 - 6-¾" Frame
⅛" Inset Door - Cylindrical Latch DS4530 - 5-¾" Frame DS4540 - 6-¾" Frame
| Model Number | Frame Size | Strike Height | Latch Type | Door Inset |
|---|---|---|---|---|
| DS4510 | 5-¾" | 2-¾" | Cylindrical | Center Hung |
| DS4520 | 6-¾" | 2-¾" | Cylindrical | Center Hung |
| DS4530 | 5-¾" | 2-¾" | Cylindrical | ⅛" Inset |
| DS4540 | 6-¾" | 2-¾" | Cylindrical | ⅛" Inset |
