DOOR PULLS & PUSH BARS SWINGING DOORS

HARDWARE

• 1" Diameter Solid Aluminum Round
• 3-1/4" Offset
• Projection 3-1/4"
• Door Clearance 2-1/4"
• CTC 9", 10" and 12"
• Anodized Finishes AL & DU (Storefront Bronze)
• Other Finishes Available on Request
• Mounting Hardware Include

SPECIFY: Length, Finish & Mounting Hardware (T1 or T6)

OFFSET DOOR PULL PH-4000 OFFSET PULL SET PH-4000-2

• 1" Diameter Solid Aluminum Round
• 3-1/4" Offset
• Projection 3-1/4"
• Door Clearance 2-1/4"
• CTC 9", 10" and 12"
• Anodized Finishes AL & DU (Storefront Bronze)
• Other Finishes Available on Request
• Mounting Hardware Included (T5)

SPECIFY: Length and Finish

OFFSET PULL & SINGLE BEND PUSH BAR SET PP-1000

• 1" Diameter Solid Aluminum Round
• Projection: See Pull/Push Specifications
• CTC: See Pull/Push Specifications
• Anodized Finishes AL & DU (Storefront Bronze)
• Other Finishes Available on Request
• Mounting Hardware Included

SPECIFY: Length, Finish & Mounting Hardware

OFFSET PULL & DOUBLE BEND PUSH BAR SET PP-2000

• 1" Diameter Solid Aluminum Round
• Projection: See Pull/Push Specifications
• CTC: See Pull/Push Specifications
• Anodized Finishes AL & DU (Storefront Bronze)
• Other Finishes Available on Request
• Mounting Hardware Included

SPECIFY: Length , Finish & Mounting Hardware

• 1" Diameter Solid Aluminum Round
• Projection 2-1/4" with 1-1/4" Door Clearance
• CTC 33-1/16",39-1/16" and 45-1/16"
• Anodized Finishes AL & DU (Storefront Bronze)
• Other Finishes Available on Request
• Mounting Hardware Included

SPECIFY: Length, Finish & Mounting Hardware (T1 or T6)

International Door Closers, Inc.

COPYRIGHT 2018 INTERNATIONAL DOOR CLOSERS, INC www.intldoorclosers.com

MOUNTING HARDWARE FOR VARIOUS COMBINATIONS

• Single Push/Pull: Specify either T1 Thru Bolt, or T6 Concealed Mount
• Push/Pull Sets: Back to Back at Bottom of Pull, Thru Bolts on free ends

West: 800-544-4422 • East: 800-225-6737
