DOOR CLEARANCES FOR HALF SURFACE GEAR HINGES

A460 SHOWN FOR EXAMPLE PAIR DOORS SQUARE EDGE

A460 SHOWN FOR EXAMPLE SINGLE DOOR SQUARE EDGE

DOUBLE DOOR CLEARANCE

TOTAL WIDTH CLEARANCE	HINGE SIDE CLEARANCE (2X) LATCH SIDE CLEARANCE
9/16"	3/16" 3/16"

TO DETERMINE DOOR WIDTH SUBTRACT THE TOTAL WIDTH CLEARANCE FROM THE WIDTH OF THE FRAME OPENING;

DIVIDE THE RESULT BY 2

SINGLE DOOR CLEARANCE

TOTAL WIDTH CLEARANCE	HINGE SIDE CLEARANCE LATCH SIDE CLEARANCE
5/16"	3/16" 1/8"

TO DETERMINE DOOR WIDTH SUBTRACT THE TOTAL WIDTH CLEARANCE FROM THE WIDTH OF THE FRAME OPENING.

NOTE:

FOR DOUBLE DOOR ENTRANCES WITH A MULLION $\{\backslash color\{red\}\; \{\backslash bf\; BETWEEN\}\}$ THE PAIR OF DOORS CALCULATE EACH DOOR WIDTH USING THE SINGLE DOOR CLEARANCES.

FOR DOUBLE DOOR ENTRANCES WITH A MULLION BEHIND THE PAIR OF DOORS, CALCULATE EACH DOOR WIDTH USING THE DOUBLE DOOR CLEARANCES.

OOR CLOSER

1140 KRAEMER PLACE, ANAHEIM, CA 92806

TEL: (714) 666-0390 (800) 544-4422 FAX: (714) 666-2215

DOOR CLEARANCE HALF SURFACE-INTERNATIONAL DOOR CLOSER-00.DWG

A211,A213,A450,A460, A530,A540,A550

ISSUED 01-22-10
