DEADBOLT LOCKS

ANSI/BHMA CERTIFIED GRADE 1

DBD Series is a heavy duty commercial quality deadbolt. Tamper resistant solid brass one piece housing provides a positive deterrent to forced entry.

Performance Features

• Certified ANSI/BHMA A156.5-2001 Grade 1
• Door Thickness: 1-9/16"-2" (40mm-51mm)
• Backset: 2-3/4" (70mm) standard, 2-3/8" (60mm) optional
• Deadbolt: Solid brass with hardened steel rod insert, full 1" (25.4) throw
• Strike: 2-3/4" X 1-1/8" lipless
• Combo screw pack: for wood or metal door or frame
• Cylinder: 6pin solid brass pick resistant pin and anti-drill bearing balls inserted, Schlage C keyway
• SFIC: Small format IC Core available
• Keying: Keyed Alike, Master Keyed and Grand Masterkeyed available
• Finishes: US26D, US10B stock finishes, other finishes upon request
• Door prep: 1" edge bore for deadbolt, 2-1/8" for lock

DBD-61

DBDI-62

DBD-81

Code Compliance

ANSI/BHMA: ANSI/BHMA A156.5-2001 Certified Grade 1

UL: UL listed 3 hour fire rating

BAA: Meets guidelines of the Buy American Act

How to order

Series	Function	Finish	Backset	Keying
DBD: Heavy duty deadbolt DBDI: Heavy duty deadbolt W/SFIC less core	61: Single Cylinder W/Thumb Turn 62: Double Cylinder 81: Single Cylinder W/Blank Plate 90: Classroom	US10B US26D	2-3/4" 2-3/8"	KD: Keyed Different KA: Keyed Alike MK: Master Keyed GMK: Grand Master Keyed

Order Sample:

DBD: Heavy duty deadbolt 61: Single cylinder with thumb turn 10B: Oil rubbed bronze 2-3/4: 2-3/4" Backset MK: Master keyed
