MORTISE & RIM CYLINDERS • CYLINDER GUARD • LOCK INDICATOR

CYLINDERS

HARDWARE

CZ-1001 (ZINC) MORTISE KEY CYLINDER TZ-3001 (ZINC) MORTISE THUMBTURN CYLINDER

• 1" Length 5 pin Cylinder 1-5/32" diameter
• AR MS-Type cam
• Keyway available: Schlage "C", Yale "8"
• Core face and Key US 26D
• Cylinder ring 3/16" standard, 5/32" and 7/32" optional
• Finishes Available: Specify : Keyway
  • AL Anodized Satin Aluminum
  • BK Anodized Black
  • DU Anodized Bronze

Specify: Cylinder ring type KA-2 or KA-(quantity) Finish

• 1" Length Cylinder 1-5/32" diameter
• AR MS-Type cam
• Thumbturn US 26D
• Cylinder ring 3/16" standard, 5/32" and 7/32" optional
• Finishes Available:
  • AL Anodized Satin Aluminum
• BK Anodized Black
• DU- Anodized Bronze

Specify: Cylinder ring type

DC-2001 (ZINC) MORTISE DUMMY CYLINDER

• 7/8" Length Cylinder
• 1-5/32" diameter
• No Keyway or cam
• Cylinder ring 3/16" standard, 5/32" and 7/32" optional
• Finishes Available: Specify: Cylinder ring type
  • AL Anodized Satin Aluminum Finish
  • BK Anodized Black
  • DU Anodized Bronze

Specify: Cylinder ring type

CG-4043 CYLINDER GUARD

• Hardened steel security ring
• Free-spinning beveled collar
• For standard face 5 pin Mortise key cylinder
• For use on Aluminum
• Furnished with retaining clip and two spacers
• Finishes Available:
  • AL Baked Satin Aluminum Paint
  • BK Baked Black Paint
  • DU- Baked Storefront Bronze Paint

Specify: Finish

RZ-1003 (ZINC) RIM CYLINDER

• 5 pin Cylinder
• Core face and Key US 26D
• Schlage "C" Keyway
• Low profile Cylinder ring and adaptor plate standard
• 1-7/8" Break-away screws and 1-1/4" Break-away Spindle standard
• Finishes Available:
  • AL Anodized Satin Aluminum
  • BK Anodized Black
  • DU Anodized Bronze

Specify: Finish

LI-4089 LOCK INDICATOR SET

• For use with DH-1820 and DT-1850 type Deadlocks
• LOCKED in red and OPEN in green letters on white background
• Includes adhesive backed HS-4089

Header Sign THIS DOOR MUST REMAIN UNLOCKED DURING BUSINESS HOURS

• Finishes Available:
  • AL Baked Satin Aluminum Paint
  • BK Baked Black Paint
• DU- Baked Storefront Bronze Paint

Specify: Finish
