The Corbin Russwin SE LP10 combines the ease and convenience of Integrated Wired technology with the heightened security and flexibility of multiCLASS SE® technology from HID Global®. This integrated lock offers an ideal solution for mixed credential environments and provides an easy transition to different credential technologies.

SE LP10

Integrated Wired Access Control

SPECIFICATIONS AND SYSTEM REQUIREMENTS

• Reader: 12VDC
• Mortise locks, multi-point locks, and exit devices from 12-24VDC; cylindrical locks available as 12 or 24VDC
• Mortise locks, multi-point locks, and exit devices field selectable to fail-safe or failsecure; must specify fail-safe or fail-secure for cylindrical locks

Credential Support:

• The SE LP10 features HID® multiCLASS SE® technology to support the following credentials:
• 2.4 GHz credentials:
• Secure Identity Object™ (SIO) on Mobile IDs (Bluetooth Smart)
• 13.56 MHz credentials:
• Secure Identity Object™ (SIO) on iCLASS Seos, iCLASS SE/SR, MIFARE DESFire EV1/EV2 and MIFARE Classic (on by default)
• Standard iCLASS Access Control Application, ISO14443A (MIFARE) CSN, ISO14443B CSN, and ISO15693 CSN
• ISO14443A/B (PIV-compatible Transparent FASC-N read) available with SE LP10-F
  • NFC-enabled mobile phones
• 125 kHz credentials:
  • HID Prox®, AWID, EM4102

Available through Authorized Channel Partners only. Contact your ASSA ABLOY Door Security Solutions sales consultant for details.

Sold through: Installed by:

Features	Benefits

multiCLASS SE® Technology from HID Global®

• Open architecture platform Compatibility with all popular access control systems
  • Provides heightened security
  • Supports:
    • Multiple credential technologies, offering easy migration to higher security credentials or consolidation of mixed credentials
    • HID Mobile Access® powered by Seos®, for both iOS® and Android™ devices

• Intelligent power management Reduces reader power consumption by as much as 75%
• Lockdown capable Ability to secure areas immediately from central security system

Technology

• Features EcoFlex® technology Featured in all electrified mortise locks, multi-point locks and exit devices
  • Reduces energy consumption up to 96%, as certified by GreenCircle
  • Field configurable to fail-safe or fail-secure
  • Operates from 12-24VDC, offering greater flexibility in system design
  • Innovative actuator design provides superior reliability

Integrated design incorporates all access control components, including card reader, door position switch and request-to-exit monitoring sensors

• Significantly reduces installation time with fewer components and a single wire harness

Integrated ANSI/BHMA Grade 1 hardware, available in cylindrical lock, mortise lock, multipoint lock, and exit device configurations

• Flexibility to support a variety of door applications; industry leading Grade 1 hardware offers the highest degree of physical security available in access control locks

Installation

Provided with pre-terminated ElectroLynx® connectors

• Direct Wiegand output Eliminates the need for an interface panel
  • Reduced installation time and costs; improved reliability

TYPICAL SYSTEM CONFIGURATION
