OVERHEAD DOOR HOLDERS & STOPS CONCEALED / SURFACE MOUNT
All Overhead Holders/Stops meet ANSI 156.8. Available in all BHMA finishes. When ordering, indicate model number, conflicting hardware, mounting means of the door, door frame opening, thickness of door and finish. N SERIES Overhead Holders/Stops contain all stainless steel components.
1000 SERIES
- For exterior, vestibule or interior single or double acting door
- All stainless steel components
- Prefix N
- Hold-open knob can be disengaged to act as a stop only
- Maximum door opening 110° , minimum door thickness 1-3/4"
1000 SERIES ADJ ADJUSTABLE
- For exterior, vestibule or interior single or double acting door
- All stainless steel components
- Prefix N
- Single point hold-open is field adjustable from 85° to 110°
- Hold-open knob can be disengaged to act as a stop only
- Maximum door opening 110° , minimum door thickness 1-3/4"
1000SL SERIES SLIM LINE
- For exterior, vestibule or interior single or double acting door
- All stainless steel components
- Prefix N (Stop Only)
- 3/4" maximum channel depth
- Maximum door opening 110°, minimum door thickness 1-3/4"
HEAVY DUTY - CONCEALED
| DOOR FRAME OPENING | HOLDER NUMBER | |||
|---|---|---|---|---|
|
BUTTS OFFSET
PIVOTS |
CENTER HUNG |
HOLD
OPEN |
STOP | FRICTION |
| 27" - 29 15/16" | 30" - 32 15/16" | 1011 | 1021 | 1031 |
| 30" - 35 15/16" | 33" - 38 15/16" | 1012 | 1022 | 1032 |
| 36" - 39 15/16" | 39" - 42 15/16" | 1013 | 1023 | 1033 |
| 40" - 43 15/16" | 43" - 46 15/16" | 1014 | 1024 | 1034 |
| 44" + GREATER | 47" + GREATER | 1015 | 1025 | 1035 |
| BHMA NUMBER | C01511 | C01541 | C01531 | |
| FED. SPEC TYPE | 1160 | — | ||
HEAVY DUTY - CONCEALED
| DOOR FRAME OPENING | HOLDER NUMBER | ||
|---|---|---|---|
| BUTTS OFFSET PIVOTS |
HOLD
OPEN |
STOP | FRICTION |
| 27" - 29 15/16" | 1011A | 1021A | 1031A |
| 30" - 35 15/16" | 1012A | 1022A | 1032A |
| 36" - 39 15/16" | 1013A | 1023A | 1033A |
| 40" - 43 15/16" | 1014A | 1024A | 1034A |
| 44" + GREATER | 1015A | 1025A | 1035A |
| BHMA NUMBER | C01511 | C01541 | C01531 |
| FED. SPEC TYPE | 1160 | — | |
HEAVY DUTY - CONCEALED
| DOOR FRAME OPENING | HOLDER NUMBER | |||
|---|---|---|---|---|
|
BUTTS OFFSET
PIVOTS |
CENTER HUNG | HOLD OPEN | STOP | |
| 27" - 29 15/16" | 30" - 32 15/16" | 1011SL | 1021SL | |
| 30" - 35 15/16" | 33" - 38 15/16" | 1012SL | 1022SL | |
| 36" - 39 15/16" | 39" - 42 15/16" | 1013SL | 1023SL | |
| 40" - 43 15/16" | 43" - 46 15/16" | 1014SL | 1024SL | |
| 44" + GREATER | 47" + GREATER | 1015SL | 1025SL | |
|
BHMA NUMBER
C01511 |
C01541 | |||
| FED. SPEC TYPE | 1160 | — | ||
International Door Closers, Inc.
1000SL SERIES ADJ SLIM LINE
- For exterior, vestibule or interior single or double acting door
- 3/4" maximum channel depth
- Maximum door opening 110° , minimum door thickness 1-3/4"
- Single point hold-open is field adjustable from 85° to 110°
HEAVY DUTY - CONCEALED
| DOOR FRAME OPENING | HOLDER NUMBER | ||
|---|---|---|---|
| BUTTS OFFSET PIVOTS | HOLD- OPEN | STOP | |
| 27" - 29 15/16" | 1011SA | 1021SA | |
| 30" - 35 15/16" | 1012SA | 1022SA | |
| 36" - 39 15/16" | 1013SA | 1023SA | |
| 40" - 43 15/16" | 1014SA | 1024SA | |
| 44" + GREATER | 1015SA | 1025SA | |
| BHMA NUMBER | C01511 | C01541 | |
| FED. SPEC TYPE | 1160 | — | |
3300 SERIES ADJ ADJUSTABLE
- For interior, single acting doors
- All stainless steel components Prefix N
- Single point hold-open is field adjustable from 85° to 110°
- Maximum door opening 110° , minimum door thickness 1-3/8"
- Available in all BHMA finishes
MEDIUM DUTY - SURFACE MOUNT
| DOOR FRAME OPENING | HOLDER NUMBER | ||
|---|---|---|---|
| BUTTS OFFSET PIVOTS |
HOLD
OPEN |
STOP | FRICTION |
| 24" - 2915/16" | 3311A | 3321A | 3331A |
| 30" - 35 15/16" | 3312A | 3322A | 3332A |
| 36" - 42" | 3312A | 3333A | 3333A |
3400 SERIES HOLDER/STOP MEDIUM DUTY OVERHEAD - SURFACE MOUNT
- For doors that don't extend to the frame header
- Ideal for dressing room doors, washroom stall doors with frames
- For interior doors with existing parallel arm closers when push side holder would be in conflict with closer .
- All stainless steel components Prefix N
- •90°, 95°, 100° degree standard door opening –
- •Contact factory for other degrees of opening
- Hold open can be made inactive for stop only function
- Minimum door size 24"
- For doors mounted on butt type hinges
- US32D standard, other architectural finishes available
3500 Series PARALLEL ARM HOLDER
HEAVY DUTY - SURFACE MOUNT
- For exterior, vestibule and interior single acting doors 24"to 36"
- 180°, maximum door opening
- Adjustable hold open from 135° to 180°
- Heavy gauge steel and cast iron construction
- Handed, specify when ordering
- Requirements: 1-1/2" min. frame soffit width, 1-3/4" min. top rail, 5" max. butt hinges
- Painted finishes standard
- Auxiliary stop recommended
West: 800-544-4422 • East: 800-225-6737
4000 SERIES
- For interior single or double acting doors
- All stainless steel components Prefix N
- Maximum door opening 110°, minimum door thickness 1-3/8"
- Hold-open can be disengaged to act as a stop only
MEDIUM DUTY - CONCEALED MOUNT
| DOOR FRAME OPENING | HOLDER NUMBER | |||
|---|---|---|---|---|
|
BUTTS OFFSET
PIVOTS |
CENTER HUNG |
HOLD
OPEN |
STOP | FRICTION |
| 18" - 23 15⁄16" | – | 4011 | 4021 | 4031 |
| 24"- 29 15⁄16" | – | 4012 | 4022 | 4032 |
| 30" - 35 15⁄16" | 32" - 37 15⁄16" | 4013 | 4023 | 4033 |
| 36" - 48" | 38" - 48" | 4014 | 4024 | 4034 |
| BHMA NUMBER | C04511 | C04541 | C04531 | |
| FED. SPEC TYPE |
1166
1166A |
1164 | ||
4400 SERIES
- For interior single acting doors
- All stainless steel components Prefix N
- Hold-open can be disengaged to act as a stop only
- Maximum door opening 110°, minimum door thickness 1-3/8"
MEDIUM DUTY - SURFACE MOUNT
| DOOR FRAME OPENING | HOLDER NUMBER | |||
|---|---|---|---|---|
|
BUTTS OFFSET
PIVOTS |
CENTER HUNG |
HOLD
OPEN |
STOP | FRICTION |
| 18" - 23 15⁄16" | 22" - 27 7⁄16" | 4411 | 4421 | 4431 |
| 24" - 29 15⁄16" | 27 1/2"- 33 7⁄16" | 4412 | 4422 | 4432 |
| 30" - 35 15⁄16" | 33 1 ⁄2"-38 | 4413 | 4423 | 4433 |
| 36" - 48" | 15⁄16" | 4414 | 4424 | 4434 |
| 39" - 48" | ||||
| BHMA NUMBER | C05511 | C05541 | C05531 | |
| FED. SPEC TYPE | 1166 | 1166A | 1164 | |
7000 SERIES
- For exterior, vestibule and interior single acting doors
- For all stainless steel components, Prefix N
- Maximum door opening 110°, minimum door thickness 1-1/4"
- Wood, machine screws and grommet nuts included
HEAVY DUTY - SURFACE MOUNT
| DOOR FRAME OPENING | HOLDER NUMBER | ||
|---|---|---|---|
|
BUTTS OFFSET
PIVOTS |
CENTER HUNG | HOLD OPEN | STOP |
| 23" - 28 15⁄16" | 24" - 31 15⁄16" | 7010 | 7020 |
| 29" - 34 15⁄ 16" | 32" - 38 7⁄16" | 7011 | 7021 |
| 35" - 40 15⁄16" | 38 1⁄2" - 44 3⁄16" | 7012 | 7022 |
| 41" - 46 15⁄16" | 44 1⁄4" - 50 3⁄16" | 7013 | 7023 |
| 47" + Greater | 50 1⁄4" - 60" | 7014 | 7024 |
| BHMA NUMBER | C08511 | C08541 | |
| FED. SPEC TYPE | GJ70 | GJ70 | |
HD7000 SERIES
- Ideal for cell doors, vault doors
- Maximum door opening 110°, minimum door thickness 1-3/4"
- Wood, machine screws and sex bolts included
- For all stainless steel components, Prefix N
EXTRA HEAVY DUTY - SURFACE MOUNT - EXTRA HEAVY DUTY
| DOOR FRAME OPENING | HOLDER NUMBER | ||
|---|---|---|---|
|
BUTTS OFFSET
PIVOTS |
CENTER HUNG | HOLD OPEN | STOP |
| 224" - 29 15 ⁄16" | 26" - 31 15⁄16" | HD7010 | HD7020 |
| 30" - 35 15⁄16" | 32" - 38 15⁄16" | HD7011 | HD7021 |
| 36" - 39 15⁄16" | 39" - 42 15⁄16" | HD7012 | HD7022 |
| 40" - 47 15⁄16" | 43" - 50 15⁄16" | HD7013 | HD7023 |
| 48" + Greater | 51" + Greater | HD7014 | HD7024 |
| BHMA NUMBER | C08511 | C08541 | |
| FED. SPEC TYPE | GJ70 | GJ70 | |
International Door Closers, Inc.
COPYRIGHT 2018 INTERNATIONAL DOOR CLOSERS, INC www.intldoorclosers.com
West: 800-544-4422 • East: 800-225-6737
8000 SERIES
- For exterior, vestibule and interior single acting doors
- Maximum door opening 110°, minimum door thickness 1-1/4"
- Sex bolts provided for the door portion
- Available in all BHMA plated finishes and US32 & US32D
9000 SERIES
- For exterior, vestibule and interior single acting doors
- All stainless steel components Prefix N
- Hold-open can be disengaged to act as a stop only
- Maximum door opening 110°, minimum door thickness 1-3/4"
- Available in all BHMA finishes including US32 & US32D
HEAVY DUTY - SURFACE MOUNT
| DOOR FRAME OPENING | HOLDER NUMBER | ||
|---|---|---|---|
|
BUTTS OFFSET
PIVOTS |
CENTER HUNG | HOLD OPEN | STOP |
| 27" - 32 7⁄16" | 29 1 ⁄2" - 34 15⁄ 16" | 8010 | 8020 |
| 32 1⁄2" - 38 11⁄16" | 35" - 41 7⁄16" | 8011 | 8021 |
| 38 3⁄4" - 42 7⁄16" | 41 1⁄2" - 44 15⁄ 16" | 8012 | 8022 |
| 42 1⁄2"+ Greater | 45" + Greater | 8013 | 8023 |
| BHMA NUMBER | C03511 | C03541 | |
| FED. SPEC TYPE | GJ80 | GJ80 | |
HEAVY DUTY - SURFACE MOUNT
| DOOR FRAME OPENING | HOLDER NUMBER | |||
|---|---|---|---|---|
|
BUTTS OFFSET
PIVOTS |
CENTER HUNG |
HOLD
STOP OPEN |
FRICTION | |
| 28" - 29 15⁄16" | 30" - 33 15⁄16" | 9011 | 9021 | 9031 |
| 30" - 31 15⁄16" | 34" - 35 15 ⁄16" | 9012 | 9022 | 9032 |
| 32"- 35 15 ⁄16" | 36" - 38 15⁄16" | 9013 | 9023 | 9033 |
| 36" - 39 15⁄16" | 39" - 40 15⁄16" | 9014 | 9024 | 9034 |
| 40" - 41 15⁄16" | 41" - 44 15⁄16" | 9015 | 9025 | 9035 |
| 42" - 43 15⁄16" | 45" - 46 15⁄16" | 9016 | 9026 | 9036 |
| 44" + Greater | 47" + Greater | 9017 | 9027 | 9037 |
|
BHMA NUMBER
C02511 C02541 |
C02531 | |||
| FED. SPEC TYPE | 1161 | 116A | ||
9000 SERIES ADJ ADJUSTABLE
- For exterior, vestibule and interior single acting doors
- For all stainless steel components, Prefix N
- Single point hold-open, field adjustable from 85° to 110°
- Hold-open can be disengaged to act as a stop only
- Maximum door opening 110°, minimum door thickness 1-3/4"
- Available in all BHMA finishes including US32 & US32D
HEAVY DUTY - SURFACE MOUNT
| DOOR FRAME OPENING | HOLDER NUMBER | ||
|---|---|---|---|
| BUTTS OFFSET PIVOTS |
HOLD
OPEN |
STOP | FRICTION |
| 28" - 31 15 ⁄16" | 9011A | 9021A | 9031A |
| 32" - 39 15 ⁄16" | 9012A | 9022A | 9032A |
| 40" - 43 1 5⁄16" | 9013A | 9023A | 9033A |
| 44" + Greater | 9014A | 9024A | 9034A |
