Clearpath S-TRX-J Spectrum Jamb Mount Transceiver Specification Sheet

SPECTRUM JAMB MOUNT CLEARPATH™ S-TRX-J

TRANSCEIVER

ClearPath™ S-TRX-J Spectrum Jamb Mount Transceiver

PRODUCT DESCRIPTION

The S-TRX-J Transceiver is a part of the ClearPath Spectrum Wireless System. When used in conjunction with the S-COR Coordinator, the S-TRX-J functions in a similar role as traditional wireless transmitters, but this is where the similarities end. The Spectrum Wireless System provides several industry firsts:

• Digital two-way communicationallows for greater security andensures successful signal transmission between devices.
• LCD screen (S-COR) for quickand easy programming.
• Upon switch activation, theTransceivers communicatevaluable information that isdisplayed on the LCD screenincluding: device ID, signalstrength and battery monitoring.
• Pairing of multiple Transceiverswith Coordinators.
• Two built-in outputs (S-COR).
• 3 year battery life (S-TRX-J).

ClearPath Spectrum products operate at 2.4 GHz, making the wave length more than 5 times shorter than commonly-used frequencies. Shorter waves pass through cracks and barriers easier, and transceivers will continue to attempt to contact the Coordinator until it receives an acknowledgement.

American National Standards Institute (ANSI) - Building Hardware Manufacturers Association (BHMA) - ANSI/ BHMA A156.10 & A156.19.

OPTIONS

• S-TRX-J = Spectrum Transceiver with 1010 Jamb Mounting Box
