PRODUCT DESCRIPTION

The CP/TX wall mount transmitter is part of the ClearPath Radio Control Push Plate Switch Activation System that provides the most reliable wireless activation of automatic doors available.

The CP/TX transmitter comes prewired and installed with battery in a surface mount box making installation quick and easy. The CP/TX can transmit three different frequencies. If interference is encountered on one frequency, simply switch to one of the other frequencies to solve the problem. The CP/TX can also be used interchangeably with other manufacturer's products that operate on its frequencies as well. Only ClearPath offers this flexibility.

American National Standards Institute (ANSI) - Building Hardware Manufacturers Association (BHMA) - ANSI/BHMA A156.10 & A156.19.

(Pictured with 59-H—Switches availableseparately or included in

TECHNICAL DATA

Utilizes Proprietary High Definition Radio Control™ (HDRC™) For Unsurpassed Signal Transmission Clarity
Three User Selectable Frequencies Available In Single Unit: HDRC™, 300 MHz, 390 MHz
FCC License For All Three Frequencies
SignalLock™ Guarantees Signal Transmission When Push Plate Switch Is Pressed
Power Saving Circuitry Extends Battery Life
Integrated Signal Radiating Antenna Boosts Signal Strength
Transmitter And Battery Factory Prewired And Installed In Mounting Boxes
Powered By Standard 9V Battery
Quick Battery Access
Sequencing Transmitter Available (CP/STX)
Temperature Range: -4°F to 140°F (-20°C to 60°C)

CP/TX Radio Transmitter (Pictured with 59-H—Sold Separately)

West: 800-544-4422 • East: 800-225-6737
