SPECIAL PURPOSE PRODUCTS
| CAMDEN | RCI | SECURITRON | SCHLAGE | SDC | DYNALOCK | ROFU |
ALARM
CONTROLS |
|
|---|---|---|---|---|---|---|---|---|
| Blue Pull Station |
CM-701
CM-702 |
904 | N/A | N/A | 492 | N/A | N/A | N/A |
|
Remote Release Switch
SPDT Momentary |
CM-830
CM-850 |
909 | PB3ER | 660 | 15-2 | 6336 | 1010 | TS-18 |
| Request to Exit Sensor | CM-RQE70 | 915 | XMS | SCAN11 | MD-31D | N/A | DS-150i | SREX-100 |
|
Power Transfer Cable – 12" /
18" |
CM-PTS14 | 9507-12S | TSB | 788/12 | PT-2V | 9300 | 10318 | DL-1 |
|
Heavy Duty
Power Transfer Cable – 12" |
CM-PT14 | 9508 | N/A | N/A | PT-3V | N/A | N/A | DL-2 |
|
Concealed Heavy Duty Power
Transfer Cable |
CM-PT516M | 9512 | EPT | N/A | PT-5 | N/A | N/A | N/A |
|
Power Supply
1 Amp. Output, UL Listed |
CX-PS1OUL | 10-175UL | BPS-24-1 | PS902 | 602RF | 5025 | 9175 | N/A |
|
Power Supply
3 Amp. Output, UL Listed |
CX-PS3OUL |
10-5-
24VDC |
BPS-12-3 | PS904 | 634RF | 5500/FAC | N/A | N/A |
|
Time Delay 1-30sec
12/24V AC/DC 2AMP. SPDT |
CX-1000/74 | N/A | TM-9 | N/A | 10TD | 7080 | N/A | MT-1 |
|
Time Delay 1sec-4hrs
12/24V DC 5AMP. SPDT |
CX-1000/77 | N/A | TM-2 | N/A | N/A | N/A | N/A | UT-1 |
|
Timer 7 Day 8 Event
12V AC/DC or 24V AC/DC |
CX-247 | N/A | DT-7 | N/A | 14-2 | 7086 | N/A | T-7P |
Note: Specifications are subject to change without notice. (OCTOBER 11, 2017)
