CX-WEC Series Emergency Call Systems For Universal & Barrier Free Restroom Control

Camden Door Control CX-WEC Series offers individual components & complete equipment packages designed to meet building code requirements for Universal & Barrier Free restroom applications.

Emergency Call Systems include a wide selection of activation switches, audible and visual annunciation and signage.

Highlighted in the CX-WEC10BK2 Universal Emergency Call System Kit is our New multicolor CM-AF142SO Annunciator. This single gang LED dome light with adjustable sounder is selectable in red, green, blue and white providing added assurance to any potential accident.

Features

  • • Ideal for universal restrooms with or without low energy door operators.
  • • Annunciation inside and outside restroom with audible sound adjustment.
  • • Push/pull 'Press for Emergency Assistance' maintained mushroom push button or with latching relay for use with momentary switches, including tape (ribbon) switches.
  • • New single gang multi-color LED dome light with sounder (Red, Green, Blue or White) is offered as an individual component or in the CX-WEC10BK2 emergency control kit.
  • • CX-WEC Series emergency call systems are available in English, French and Bilingual.
  • • Compatible with all Camden 'CX-WC' barrier free restroom control kits.
  • • 3 year warranty

CX-WEC: EMERGENCY CALL SYSTEM COMPONENTS FOR UNIVERSAL & RESTROOM APPLICATIONS

Camden Door Controls offers the industry's largest selection of control, activation and locking products specifically designed for use in any universal and barrier free restroom control application. Each component offers the best quality and performance, backed by the best warranty in the industry.

See individual product specification sheets for a complete list of product information for each model shown.

CM-450R/12: Mushroom Push Button 1-5/8" Mushroom Push Button, Push/Pull, 'Press For Emergency Assistance'

  • Push/pull maintained operation
  • Single gang stainless steel faceplate
  • 5 Inputs, including a 'wet' input
  • Large 3 segment display is easier to view and understand, than competitive models.

CM-AF540S0: Double Gang 'Press For Emergency Assistance' Push Button & LED Annunciator

  • Double gang, combining activation and annunciation in one device
  • 1-5/8" Maintained mushroom push button
  • Super bright led illumination
  • White out 'ASSISTANCE REQUESTED' message only legible upon activation

CM-AF501S0: Single Gang LED Annunciator with Adjustable Sounder

  • White out 'ASSISTANCE REQUESTED' message only legible upon activation
  • Single gang heavy duty brushed stainless steel faceplate
  • Super bright LED illumination
  • Field adjustable 85 DB Piezo sound alert, designed to confirm request

CM-AF141S0/CM-AF142S0: 'Assistance Required' Dome Light with Adjustable Sounder

  • CM-AF141S0: white only
  • CM-AF142S0: red/blue/green/white
  • Weather & vandal resistant for indoor or outdoor use
  • Loud 93 DB Piezo sounder, with volume adjustment
  • Super bright LED illumination
  • 'ASSISTANCE REQUIRED' text on lens (Eng., Fr. & bilingual)
  • 4" W x 5 1/2" H dress plate included

CX-LRS12/CX-LRS24: Latching Relay Assembly For Emergency Call System

  • For use with momentary 'PRESS FOR ASSISTANCE' switches
  • Selection of 12V or 24V latching relays

CM-SE21A/CM-SF20A: Instructional Signage for Universal Restrooms

  • Complies with Ontario building code requirements
  • White, 1/16" (1.6mm) thick panel, 6"H x 10 5/8"W, (152mm x 270mm)
  • Fire rated expanded PVC
  • Red 1" (25mm) lettering
  • Easily mounts to wall (glue or screws)

SPECIFICATIONS DIMENSIONS CM-450R/12: Mushroom Push Button (1-5/8"), Push/Pull, 'Press For Emergency Assistance' 12/24V AC/DC VOLTAGE: CONTACT TYPE: DPST, Maintained ASSISTANCE CONTACT RATING: 10 Amps 4 ½" (114mm) STANDARD FINISH: Stainless Steel DIMENSIONS: 2 3/4" W x 4 1/2" H x 3" D (70mm x 114mm x 76mm) • (6mm) 2 3/4 CM-AF501S0: Single Gang LED Annunciator with Adjustable Sounder 6-32 x 1/2" Stud - 2 PCS • 12/30V AC/DC VOLTAGE: CURRENT DRAW: 30 - 75mA Adjustable, 85DB @ 10CM Max. SOUNDER: 1 3/8" (35mm) 4 ½" (114mm) 2 1/4" (57mm) STANDARD FINISH: Stainless Steel DIMENSIONS: 2 3/4" W x 4 1/2" H x 5/8" D (70mm x 114mm x 16mm) • 9/16" CM-AF540S0: Double Gang 'Press For Emergency Assistance' 4 ½" (114mm) Push Button & LED Annunciator 1 ½" (38mm) 1 %6" 12/30V AC/DC VOLTAGE: CURRENT DRAW: 30mA - 75mA CONTACT TYPE: DPST CONTACT RATING: 10 Amps STANDARD FINISH: Stainless Steel DIMENSIONS: 4 1/4" W x 4 1/4" H x 3 1/16" D (70mm x 114mm x 78mm) CM-AF141S0/CM-AF142S0: 'Assistance Required' Dome Light 1 %16" (40mm) 2 <sup>15</sup>/<sub>16</sub>′ (75mm) with Adjustable Sounder VOLTAGE: 12V to 24V AC/DC CURRENT DRAW: CM-AF141SO: 40mA to 70 mA 3 ½6" (77mm) CM-AF142SO: 70mA Max 1 Color 1 %16" 130mA Max Multi-Color SOUNDER: Adjustable, 93DB @ 1 Meter Max. (3 ft) FINISH: DIMENSIONS: 2 3/4" W x 4 1/2" H x 13/16" D (70mm x 114mm x 21mm) 2 ½6" (53mm) CM-1205/14: Momentary, 'W/C System Reset' 2 <sup>3</sup>/<sub>4</sub>" (70mm) Flush Mount Key Switch with Cylinder & Keys VOLTAGE: 12/24V AC/DC • CONTACT TYPE: SPST, Momentary, N/C CONTACT RATING: 6 Amps 4 ½" (114mm) 100,000 Cycles SWITCH LIFE: Stainless Steel STANDARD FINISH: DIMENSIONS: 2 3/4" W x 4 1/2" H x 3" D (70mm x 114mm x 76mm) ••)

CX-WEC: EMERGENCY CALL SYSTEM CONTROL KITS FOR UNIVERSAL & RESTROOM APPLICATIONS

Camden's CX-WEC Series equipment packages meet the latest building code requirements for universal restroom applications. These restroom control kits include a CM-450R/12 Push/pull mushroom button which serves as an audible and visual annunciator that activates/deactivates a call for emergency assistance, a single gang weather and vandal resistant dome light with sounder, and a CM-SE21A 'IN THE EVENT OF AN EMERGENCY' sign..

Our new CM-AF142SO single gang multi-colored LED dome light with adjustable sounder is featured in the CX-WEC10BK2 kit. The CM-AF142SO dome light can be selectable to red, green, blue and white for your convenience.

All equipment packages include a CM-SE21A 'IN THE EVENT OF AN EMERGENCY' sign, with 1" (25mm) lettering, as required by code.

CX-WEC10K2: Universal Emergency Call System Kit

  • (1) CM-AF540SO 'PRESS FOR ASSISTANCE' maintained mushroom push button & 'ASSISTANCE REQUESTED' LED annunciator with adjustable sounder
  • (1) CM-AF141SO Single Gang LED dome light with adjustable sounder
  • (1) CM-SE21 White panel sign, 6" x 10 5/8" (152mm x 270mm)

CX-WEC10K2

CX-WEC10BK2: Universal Emergency Call System Kit with Multi-Color LED Dome

  • (1) CM-AF540SO 'PRESS FOR ASSISTANCE' maintained mushroom push button & 'ASSISTANCE REQUESTED' LED annunciator with adjustable sounder
  • (1) CM-AF142SO Single Gang Multi-Color LED dome light with adjustable sounder
  • (1) CM-SE21 White panel sign, 6" x 10 5/8" (152mm x 270mm)

CX-WEC10BK2

CX-WEC10BK2: Universal Emergency Call System Kit with Key Switch Reset

Universal Emergency Call Kit with key switch reset. For use with momentary 'PRESS FOR EMERGENCY ASSISTANCE' switches (extra) includes:

  • (1) CM-AF540SO 'PRESS FOR ASSISTANCE' maintained mushroom push button & 'ASSISTANCE REQUESTED' LED annunciator with adjustable sounder
  • (1) CM-AF141SO Single Gang LED dome light with adjustable sounder
  • (1) CM-SE21 White panel sign, 6" x 10 5/8" (152mm x 270mm)
  • (1) CX-LRS 24V latching relay assembly
  • (1) CM-1205/14 Momentary 'W/C SYSTEM RESET' key switch
  • (1) CM-CYL60KD Mortise cylinder 1 1/8", keyed different

For a complete list of all Barrier Free Restroom Control kits, visit our website or contact Camden's customer service at (877) 226-3369.
