CX-WEC Series Emergency Call Systems For Universal & Barrier Free Restroom Control

Camden CX-WEC Series equipment kits include everything you need to meet the latest building code requirements for emergency call systems in Universal restrooms.

CX-WEC Series Emergency Call System kits include 'PRESS FOR EMERGENCY ASSISTANCE' push button, audible and visual annunciators inside and outside the restroom, and instructional signage.

Next generation CX-WEC10BK2 Universal Emergency Call System kits include a double gang push button/ annunciator and a CM-AF142SO multicolor dome light with sounder and flashing LED.

Features

  • • Ideal for universal restrooms with or without low energy door operators.
  • • Annunciation inside and outside restroom with audible sound adjustment.
  • • Push/pull 'Press for Emergency Assistance' maintained mushroom push button, or with latching relay for use with momentary switches, including tape (ribbon) switches.
  • • New single gang multi-color LED dome light with sounder (Red, Green, Blue or White) is offered as an individual component or in the CX-WEC10BK2 emergency control kit.
  • • CX-WEC Series emergency call systems are available in English, French and Bilingual.
  • • Compatible with all Camden 'CX-WC' barrier free restroom control kits.
  • • 3 year warranty

Product Specification Sheets CX-WEC Series

CX-WEC: EMERGENCY CALL SYSTEM COMPONENTS FOR UNIVERSAL RESTROOMS

Camden's emergency call system components have been specifically designed to meet the unique demands of universal restrooms in commercial and institutional applications. These exclusive products are not available elsewhere and are backed by the best warranty in the industry.

CM-450R/12: Mushroom Push Button 1-5/8" Mushroom Push Button, Push/Pull, 'Press For Emergency Assistance'

  • Push/pull maintained operation
  • Single gang stainless steel faceplate
  • Free-spinning push button to prevent vandalism
  • Stainless steel security screws supplied

CM-AF540SO: Double Gang 'Press For Emergency Assistance' Push Button & LED Annunciator

  • Double gang, combining activation and annunciation in one device
  • 1-5/8" Maintained mushroom push button
  • Super bright LED illumination
  • White out 'ASSISTANCE REQUESTED' message only legible upon activation

CM-AF501SO: Single Gang LED Annunciator with Adjustable Sounder

  • White out 'ASSISTANCE REQUESTED' message only legible upon activation
  • Single gang heavy duty brushed stainless steel faceplate
  • Super bright LED illumination
  • Field adjustable 85 DB Piezo sound alert, designed to confirm request

CM-AF141SO/CM-AF142SO: 'Assistance Required' Dome Light with Adjustable Sounder

  • CM-AF141SO: white only
  • CM-AF142SO: red/blue/green/white
  • Weather & vandal resistant for indoor or outdoor use
  • Loud 93 DB Piezo sounder with volume adjustment
  • Super bright LED illumination
  • 'ASSISTANCE REQUIRED' text on lens (Eng., Fr. & bilingual)
  • 4" W x 5 1/2" H dress plate included

CM-AF141S0 CM-AF142S0

CX-LRS12/CX-LRS24: Latching Relay Assembly for Emergency Call System

  • For use with momentary 'PRESS FOR ASSISTANCE' switches
  • Selection of 12V or 24V latching relays

CM-SE21A/CM-SF20A: Instructional Signage for Universal Restrooms

  • Complies with Ontario building code requirements
  • White, 1/16" (1.6mm) thick panel, 6"H x 10 5/8"W, (152mm x 270mm)
  • Fire rated expanded PVC
  • Red 1" (25mm) lettering
  • Easily mounts to wall (glue or screws)

SPECIFICATIONS DIMENSIONS CM-450R/12: Mushroom Push Button (1-5/8"), Push/Pull, 'Press For Emergency Assistance' 12/24V AC/DC VOLTAGE: • CONTACT TYPE: DPST. Maintained ASSISTANCE CONTACT RATING: 10 Amps 4 ½" (114mm) STANDARD FINISH: Stainless Steel DIMENSIONS: 2 3/4" W x 4 1/2" H x 1 1/2" D (70mm x 114mm x 38mm) • 2 3/4" CM-AF501SO: Single Gang LED Annunciator with Adjustable Sounder 12/30V AC/DC •• VOLTAGE: CURRENT DRAW: 30mA - 75mA SOUNDER: Adjustable, 85DB @ 10CM Max. 1 3/8" (35mm) 2 1/4" 4 1/2" (114mm) (57mm) STANDARD FINISH: Stainless Steel DIMENSIONS: 2 3/4" W x 4 1/2" H x 9/16" D (70mm x 114mm x 15mm) Þ • %16" CM-AF540SO: Double Gang 'Press For Emergency Assistance' Push Button & LED Annunciator 12/30V AC/DC VOLTAGE: 30mA - 75mA CURRENT DRAW: DPST CONTACT TYPE: 4 ½ 3 1/4 CONTACT RATING: 10 Amps STANDARD FINISH: Stainless Steel DIMENSIONS: 4 1/2" W x 4 1/2" H x 1 9/16" D (114mm x 114mm x 40mm) CM-AF141SO/CM-AF142SO: 'Assistance Required' Dome Light with Adjustable Sounder 2 <sup>15</sup>/<sub>16</sub>" (75mm) VOLTAGE: 12V to 24V AC/DC CURRENT DRAW: CM-AF141SO: 40mA to 70 mA 3 ½6" (77mm) CM-AF142SO: 70mA Max 1 Color 4 %16" (115mm) 130mA Max Multi-Color Adjustable, 93DB @ 1 Meter Max. (3 ft) SOUNDER: FINISH: White 1/2" DIMENSIONS: 2 15/16" W x 4 9/16" H x 1/2" D (75mm x 115mm x 13mm) CM-1205/14: Momentary, 'W/C System Reset' 2 ¾" (70mm) Flush Mount Key Switch with Cylinder & Keys ½" (3mm) 1 ½" VOLTAGE: 12/24V AC/DC • CONTACT TYPE: SPST, Momentary, N/C CONTACT RATING: 6 Amps 4 ½" (114mm SWITCH LIFE: 100,000 Cycles STANDARD FINISH: Stainless Steel DIMENSIONS: 2 3/4" W x 4 1/2" H x 1 1/2" D (70mm x 114mm x 38mm) ••)

CX-WEC: EMERGENCY CALL SYSTEM CONTROL KITS FOR UNIVERSAL & RESTROOM APPLICATIONS

CX-WEC Series equipment packages are designed to provide a complete solution that includes assistance request and notification that meets the latest OBC building code requirements. CX-WEC Series Emergency Call System kits are available with white only or red/green/blue/white multi-color dome lights, with sounder, and with system reset that support the use of momentary 'PRESS FOR ASSISTANCE' switches (sold separately).

CX-WEC10K2: Universal Emergency Call System Kit

  • (1) CM-AF540SO 'PRESS FOR EMERGENCY ASSISTANCE' maintained mushroom push button & 'ASSISTANCE REQUESTED' LED annunciator with adjustable sounder
  • (1) CM-AF141SO Single Gang LED dome light with adjustable sounder
  • (1) CM-SE21 White panel sign, 6" x 10 5/8" (152mm x 270mm)

CX-WEC10K2

CX-WEC10BK2: Universal Emergency Call System Kit with Multi-Color LED Dome

  • (1) CM-AF540SO 'PRESS FOR EMERGENCY ASSISTANCE' maintained mushroom push button & 'ASSISTANCE REQUESTED' LED annunciator with adjustable sounder
  • (1) CM-AF142SO Single Gang Multi-Color LED dome light with adjustable sounder and flashing LED
  • (1) CM-SE21 White panel sign, 6" x 10 5/8" (152mm x 270mm)

CX-WEC10BK2

CX-WEC13: Universal Emergency Call System Kit with Key Switch Reset

Universal Emergency Call System Kit with key switch reset. For use with momentary 'PRESS FOR EMERGENCY ASSISTANCE' switches (extra) includes:

  • (1) CM-AF501SO 'ASSISTANCE REQUESTED' LED annunciator with adjustable sounder
  • (1) CM-AF141SO Single Gang LED dome light with adjustable sounder
  • (1) CM-SE21 White panel sign, 6" x 10 5/8" (152mm x 270mm)
  • (1) CX-LRS 24V latching relay assembly
  • (1) CM-1205/14 Momentary 'W/C SYSTEM RESET' key switch
  • (1) CM-CYL60KD Mortise cylinder 1 1/8", keyed different

For a complete list of all Barrier Free Restroom Control kits, visit our website or contact Camden's customer service at (877) 226-3369.
