Door Activation Devices

CM-310EE Exit Switch & Integrated Timer (Ver. 2)

INSTALLATION INSTRUCTIONS

1. GENERAL DESCRIPTION

Camden model CM-310EE is an illuminated Exit switch incorporating a 30 second timer. The stainless steel faceplate is designed to flush mount on to a 1 ¾" wide doorjamb.

The ½" x ¾" rectangular translucent button is easy to push. CM-310EE model is supplied with a LED light bulb, which is accessed through the front of the switch. If the unit is powered 24VDC, the supplied in-line resistors must not be removed.

This switch has been designed specifically to release a magnetic lock from the inside, as per the BOCA code. When the button is pushed and released, the lock will release for 30 seconds. Re-trigger is possible at any time.

The "double break" circuitry has been designed so that even if the timer fails, depressing the switch will interrupt power to the magnetic lock.

CM-310EE

2. SPECIFICATIONS

Models	CM-300
Operating Voltage	12 or 24 V DC
Time Delay	30 seconds
Contact Rating	4 amps @ 30 VDC
Incandescent Bulb Life	15,000hrs.@ rated capacity
Mounting	2 x #6-32 machine screws
Lens Colour	Green
Legend	'PUSH TO EXIT'
Dimension	2.75" W x 4.5" H x 1 5/16" (70mm x 114mm x 33mm)

3. INSTALLATION

Mounting

The unit is completely pre-wired for easy installation. Connect the appropriate wires to your devices as per the enclosed wiring diagram. Tuck wiring into box (retrofit box included), and fasten switch plate using screws provided.

Wiring

Six color coded leads are provided. This unit will operate on 12 or 24 VDC, with no jumper change required. For convenience it may be powered by the same power that supplies the magnetic lock. The two pairs of Red & Black wires connect to 12 or 24 VDC.

One pair supplies power to the timer, and the other pair powers the light. The internal timer and the push button are connected in series with the Green & White wires. This is how the "double break" feature works. Therefore, the unit must be wired as shown.

The Green wire goes to the positive input wire of the magnetic lock, and the White wire goes to a source of + Voltage. Please refer to the enclosed wiring diagram for typical hook-up.

Important:

CM-310EE models have connected lead wires with black-colored heat shrink (over an in-line resistors).

If powered 24V; Do not remove in-line resistors. If powered 12V; Cut (remove) in-line resistor on the black lead.

4. LIMITED WARRANTY

Camden Door Controls Inc. warrants this product to be free from defects for 3 years from date of manufacturing. Visit our web site at www.camdencontrols.com to see our complete warranty policy, including limitations and the procedures for product returns.
