View PDFOverhead Holders & Stops
Options
"AJB" - Angle Jamb Brackets
Available for most surface mount models – converts standard installation to pull side mount or push side They are also available separately, as a part.
- • 44443 3300A & 4400 Series
- • 70377 7000 Series
- • 90541 8000, 9000 & 9000A Series
"CL" – For Use with Cam Lift Hinges
Custom unit for use with cam lift hinges (½" maximum door lift)
"HC" – Hold Closed
Special mechanism is integrated into the overhead stop holding the door closed at 0° and essentially doubling as a roller latch (available for stop function only). Hold-closed mechanism can be disengaged.
"LL" – Lead Lined
Lead is provided to cover where mounting holes will pierce lead on lead-lined doors.
"LS" – Less Spring
Typically used with a single point electronic door closer, overhead stop is supplied without the shock absorbing spring (stop function only).
"N" – All Stainless Steel (Non-Ferrous) Components
Designed for use in wet environments - all stainless steel or non-ferrous components are provided with the unit, including all internal components and screws.
"SEC" – Security Fasteners
Security fasteners are provided in lieu of standard fasteners for all exposed mounting holes – specify door and frame material when ordering.
"SNB" – Sex Bolts
Sex bolt fasteners are added to 3500 series surface mount model screw pack, as they are not supplied standard.
"T" – Threaded Pivot Screw and Nylon Washer in Lieu of Jamb Bracket
Typically used when space is limited in the frame head for installation or when installing a concealed model in
"THICK" – Door Thickness other than 1-¾"
Custom fasteners will be supplied to accommodate various door thicknesses other than 1-3/4" – specify door thickness.
"SPECIAL" - Special Layout
ABH can provide custom units for countless nonstandard applications. See page B-6 for order form or contact factory for assistance.
| Overhead Holder Options - Compatibility Chart | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Series | AJB | CL | НС | TT | ST | Z | SEC | SNB | T | THICK | SPECIAL | |
| Concealed Mount | 1000 | • | • | • | • | • | • | • | ||||
| 1000A | • | • | • | • | • | • | ||||||
| 1000SL | • | • | • | • | • | • | ||||||
| 1000SA | • | • | • | • | • | |||||||
| 4000 | • | • | • | • | • | • | ||||||
| Surface Mount | 3300A | • | • | • | • | • | • | • | • | • | • | |
| 3400 | • | • | • | • | • | • | • | |||||
| 3500 | • | • | • | • | • | |||||||
| 4400 | • | • | • | • | • | • | • | • | • | • | ||
| 7000 | • | • | • | • | • | • | ||||||
| HD7000 | • | • | • | • | • | |||||||
| 8000 | • | • | • | • | • | • | ||||||
| 9000 | • | • | • | • | • | • | • | • | • | • | ||
| 9000A | • | • | • | • | • | • | • | • | • | • | ||
