Auto EntryControl™
Distributor
Discount Code XK
Auto EntryControl's
non-pivot drive and combination of belt, gear and pulley requires less torque, requires less power, absorbs more abuse, and is quieter than other automatic door openers while complying with all US and Canadian ADA requirements. On-board diagnostics simplifies troubleshooting for ease of installation and all Auto EntryControl's
can be easily configured for surface mounted push/pull or overhead concealed applications.
-
ADA Compliant
-
Meets ANSI A 156.19
-
Certified for use as fire door operators (3 hour rating)
-
Self-Tunning, Self-Learning
-
Minimum 5 seconds from close to open
-
Stays open for 5 seconds
-
130 degree of opening
-
Push or Pull (In door, Out swing)
-
· Activation: Knowing Act
-
· Optional Safety Device
-
24V, 1Amp+ Output
-
Input Power: 1A, 100W
-
Non-Handed
-
· Extremely Quiet Operation
SINGLE DOOR OPENING
|
SPECIFY
|
MODEL
|
LIST
|
|
Model
|
Description
|
|
|
AUTOS
|
Single Drive Unit,
|
2,385,00
|
|
AUTUS
|
Single Door Operation
|
2,363.00
|
|
OPERAT
|
ION
|
Add to List
|
|
Operation
|
Description
|
|
|
1
|
Push Arm, 35mm Spindle
|
N/C
|
|
2
|
Pull Arm, 20mm Spindle
|
N/C
|
|
3
|
Arm Kit, (1) Push and (1) Pull Arm,
35mm and 20mm Spindles
|
290.00
|
|
DOOR O
|
PENING Add
|
to List
|
|
Width
|
Description
|
|
|
36
|
36" Door Opening, 39" Housing Length
|
N/C
|
|
42
|
42" Door Opening, 45" Housing Length
|
N/C
|
|
48
|
48" Door Opening, 51" Housing Length
|
N/C
|
|
72
|
72" Door Opening, 75" Housing Length
|
208.00
|
|
84
|
84" Door Opening, 87" Housing Length
|
208.00
|
|
96
|
96" Door Opening, 99" Housing Length
|
208.00
|
|
FINISH
|
|
Add to List
|
|
Color
|
Description
|
|
|
٧
|
628 Dull Aluminum
|
N/C
|
|
X
|
710 Dark Bronze
|
306.00
|
|
DOUBL
|
E DOOR OPENING
|
|
|
SPECIFY
|
/ MODEL
|
LIST
|
|
Model
|
Description
|
|
|
AUTOP
|
Two Drive Units,
Pair of Doors Operation
|
4,831.00
|
|
OPERAT
|
ION
|
Add to List
|
|
Operation
|
Description
|
|
|
1
|
Push Arms, 35mm Spindles
|
N/C
|
|
2
|
Pull Arms, 20mm Spindles
|
N/C
|
|
4
|
(1) Push and (1) Double Egress Arm, 80mm and 20mm Spindles
|
430.00
|
|
DOOR
|
DPENING
|
Add to List
|
|
Width
|
Description
|
|
|
72
|
72" Door Opening, 75" Housing Length
|
208.00
|
|
84
|
84" Door Opening, 87" Housing Length
|
208.00
|
|
96
|
96" Door Opening, 99" Housing Length
|
208.00
|
|
|
|
|
|
FINISH
|
|
Add to List
|
|
Color
|
Description
|
|
|
V
|
628 Dull Aluminum
|
N/C
|
|
X
|
710 Dark Bronze
|
547.00
|
CONSULT FACTORY FOR CUSTOM HOUSING LENGTHS OR SPECIAL FINISHES
Auto EntryControl™ XK
Distributor Discount Code AUTO-IR Door-mounted Presence Sensor and Door Re-Activator - 48 inches, length field-adjustable
365.00 ACCESSORIES V LIST
Distributor Discount Code AUTO-KS Single gang key lock switch
193.00
AUTO-KSN Narrow key lock switch
193.00
AUTO-RKR Narrow rocker Switch
102.00
• Apply 120 VAC Main power to the control o Place the On-O-Hold switch to the Hold Open position AUTO-PROG Handheld program module for custom configuration of the Auto EntryControl low energy operator
988.00
|
|
|
OPTIONAL ARM EXTENSIONS FOR REVEAL GREATER THAN 8 INCHES
|
|
|
|
|
|
List
|
|
AUTO-AEV
|
|
Arm Extension for PUSH arm - 628 Aluminum
|
|
|
|
|
|
107.00
|
|
AUTO-AEX
|
|
Arm Extension for PUSH arm - 710 Dark Bronze
|
|
|
|
|
|
150.00
|
|
|
|
|
|
|
|
|
|
|
|
|
OPTIONAL SPINDLES
|
|
|
|
|
|
|
List
|
|
SP20
|
20mm Spindle
|
|
81.00
|
|
|
SP50
|
50mm Spindle
|
81.00
|
