Arrow Universal Glass Door Mounting Kit Installation Instructions

801 Avenida Acaso, Camarillo, Ca. 93012 • (805) 494-0622 • Fax: (805) 494-8861 www.sdcsecurity.com • E-mail: service@sdcsecurity.com

INSTALLATION INSTRUCTIONS HDB HERCULITE GLASS DOOR BRACKET

USING BAR (SEE STEP 1) ADJUST ARMATURE PLATE AS NEEDED FOR PROPER ALIGNMENT BETWEEN ARMATURE PLATE AND EMLOCK SURFACE. FRAME HEADER GLASS DOOR SIDE VIEW GLASS DOOR CLOSED POSITION

STEP 5
