Architectural Hinges Specification Sheet

ARCHITECTURAL HINGES

FULL MORTISE BALL BEARING HINGES

Standard Weight

IDCBB814545US26D IDCBB814545US10B 5 Knuckle Ball Bearing 4.5 x 4.5 Steel Hinge, Dull Chrome 5 Knuckle Ball Bearing 4.5 x 4.5 Steel Hinge, Oil Rubbed Bronze

IDCBB514545US32D 5 Knuckle Ball Bearing 4.5 x 4.5 Stainless Steel Hinge

IDCBB814540689 IDCBB814540695 IDCBB814540800 5 Knuckle Ball Bearing 4.5 x 4.0 Hinge, Aluminum Powder Coat 5 Knuckle Ball Bearing 4.5 x 4.0 Hinge, Dark Bronze Powder 5 Knuckle Ball Bearing 4.5 x 4.0 Hinge, Black Powder Coat

Heavy Weight

IDC4B814545US26D IDC4B814545US10B 5 Knuckle Ball Bearing 4.5 x 4.5 Steel Hinge, Dull Chrome 5 Knuckle Ball Bearing 4.5 x 4.5 Steel Hinge, Oil Rubbed Bronze

IDC4B814545US32D 5 Knuckle Ball Bearing 4.5 x 4.5 Stainless Steel Hinge

IDCSP814545US26D IDCSP814545US10B Spring Hinge 4.5 x 4.5 Steel Hinge, Dull Chrome Spring Hinge 4.5 x 4.5 Steel Hinge, Oil Rubbed Bronze

FULL MORTISE SWING CLEAR BALL BEARING HINGES

IDCSCBB814545US26D Swing Clear 4.5 x 4.5 Steel Hinge, Dull Chrome

IDCSCBB814545US10B Swing Clear 4.5 x 4.5 Steel Hinge, Oil Rubbed Bronze

IDCAHP SERIES

5 Knuckle 2 Bearing Spring Hinge

Size:

• 4.0"x4.0"

• 4.5"x4.0"

• 4.5"x4.5"

• 5.0"x5.0"

• Other specs are available.

• Finishes Available:

US3, US4, US10, US10B, US26, US26D, US32, US32D, White, etc.

• Options:

NRP (Non-Removable Pin)
