Compatible with all Exit Check® systems, the 101 series annunciators provide door status at a remote location such as a nurse's station, guard station or office. The tri-color LED provides precise delay mode status.

101-1A Single Door Annunciator

• Audible alarm
• Tri-color LED status indicator

101-4AM Four Door Annunciator

• Audible alarm
• Alarm mute switch
• Four tri-color LED status indicators

101-1AK Single Door Annunciator with Key Control

• Dual function key switch for bypass (on/off) and reset. Key cylinder not included
• Audible alarm
• Tri-color LED status indicator
• Must be located adjacent to the door

101-PAM Single Door Annunciator with Push Switch Control

• Three push switches: momentary access, bypass (on/off) and audible mute
• Audible alarm
• Tri-color LED status indicator

Specifications

Faceplate: 20 gauge stainless steel

LED: Tri-color, 20 mA @ 12/24VDC

Green - Secure

Amber - Alarm/door locked Red - Alarm/door unlocked

ANNUNCIATORS

Annunciators Local Reset and Bypass

Used in lieu of the standard built-in reset and bypass, the wall mount controls provide a more accessible method of reset and bypass using the existing facility key system. All reset controls must be located adjacent to the door. (Key cylinder not included)

708RU On/Off Bypass and Reset Key Switch

• Left SPDT, maintained contact for bypass (on/off)
• Right SPDT, momentary contact for lock/alarm reset

707RU Momentary Bypass and Reset Key Switch

• Left SPDT, momentary contact for bypass (on/off)
• Right SPDT, momentary for lock / alarm reset

702RU Lock/Alarm Reset Key Switch

• SPDT, momentary contact for lock/ alarm reset

Specifications

Key Switch: 6 Amp @ 30VDC Max
