Alarm Controls Wall Plate Model RP-9 Cutsheet

MODEL RP-9

SPECIFICATIONS

• - SINGLE GANG SATIN STAINLESS STEEL WALLPLATE
• - .250 INCH DIAMETER RED AND GREEN LEDS, OPERATE ON 12 OR 24 VDC
• - LED CURRENT DRAW 8 MA. @ 12 VDC, 12 MA. @ 24 VDC
• - 6 INCH RED AND BLACK LEADS
• - RP-9 IS AVAILABLE IN ALL STANDARD PAINT FINISHES
• - PLATE SIZE IS 2.75" W x 4.5" H
• - LED ARE AVAILABLE MOUNTED IN A VERTICLE POSITION, ADD SUFFIX V TO P/N
