Alarm Controls Model SLP-2M Installation Instrutions
Open the original PDF document
View PDFSLP WIRING INSTRUCTIONS
| SWITCH WIRING | |||
|---|---|---|---|
| Wire Color | Designation | Notes | |
| Yellow | LED (+) Positive Lead | 12 or 24 Volts AC or DC | |
| Black | LED (-) Negative Lead | ||
| Blue | N/O Contact | ||
| White | Common Contact | Contacts rated 3A @ 35VDC or 120VAC | |
| Red | N/C Contact | ||
| LED WIRING FOR 12V OPERATION | |||
|---|---|---|---|
| Wire Color | Designation | Notes | |
| White | LED (+) Positive Lead | 12 Volts AC or DC | |
| Black | LED (-) Negative Lead | ||
| LED WIRING FOR 24V OPERATION | |||
|---|---|---|---|
| Wire Color | Designation | Notes | |
| Red | LED (+) Positive Lead | 24 Volts AC or DC | |
| Black | LED (-) Negative Lead | ||
Alarm Controls Corporation Deer Park, New York 11729 (800) 645-5538 www.alarmcontrols.com SLPInst7-13
