Model 300S

300 lbs Single Magnetic Lock

Specifications

• • 300 lbs holding force
• • Magnet size: 6-11/16" L x 1-1/2" H x 1-3/16" W
• • Armature size: 5-1/2" L x 1-1/4" H x 7/16" W
• • Operates on 12 or 24 VDC, switch selectable
• • Low current draw: 250 mA at 12 VDC, 130 mA at 24 VDC
• • Operating temperature: +14 to +131F [-10 to +55C]

Options

• • Clear anodized (US28) finish standard
• • Duronic (US40) finish available

Features

• • Built-in arc suppression
• • Instant release, no hysteresis
• • Non-aluminum parts are plated to resist corrosion
• • Ideal for cabinets and showcases
• • Self drilling TEC screws
• • Limited lifetime warranty

Models

300S

300 lbs Single Door Magnetic Lock, 12 or 24 VDC
