Model SREX-100

Active Focused Infrared Detector

Specifications

• • UL 294 and ULC-S319 listed as an access control device
• • Operates on 12 or 24 VAC or VDC, auto sensing
• • Double pole-double throw relay with 2A contacts
• • Current draw: 60 mA
• • Temperature range: +32F to +120F, (0C to +49C)
• • Relay contact rating is 1.3A at 30 VDC or 24 VAC

Features

• • Narrow activation zone is limited to door handle area
• • Designed to eliminate cross-traffic activation
• • Can not be deceived by placing objects under door
• • Immune to thermal changes

• • Active request to exit motion sensor
• • Easy installation and adjustable depth zone
• • Adjustable time delay from 1 to 60 seconds
• • Built-in buzzer, can be silenced if required
• • Request to exit input, keypad or card reader input and door position switch input
• • 14 pin female connector with 4 ft of cable
• • Three year warranty

Certifications & Listings

• • UL 294 listed
• • CAN/ULC-S319 listed

Models

SREX-100 Active Focused Infrared Request to Exit (REX) Motion Sensor
