Model APS-300

Dual-Voltage Access Control Power Supply

• • Universal AC input 110 to 240 VAC
• • 3A at 12 VDC, 1.5A at 24 VDC
• • Cabinet size: 14" L x 8-1/2" W x 3-1/2" D
• • Form C relay contacts, (SPDT), indicates AC power status
• • ULC listed to ULC-S318 (Canada)
• • UL listed to UL 294 and UL 603

• • Battery always online, no voltage drop or switch over when AC fails
• • Reverse battery protection, battery disconnect when battery is drained
• • Operates under brownout conditions
• • AC and DC power indicator LEDs
• • Outputs are power limited
• • Cabinet includes normallyopen tamper switch and camlock

Features

• • Sufficient power to support up to three magentic locks or electric strikes plus required exit devices
• • One Class 2 power limited output with thermal protection
• • Precise battery regulation for all sealed lead acid batteries
• • Input and output surge protection

Certifications & Listings

• • UL 294 listed
• • UL 603 recognized component
• • CAN/ULC-S319 listed

Models

APS-300

Power Supply 12 or 24V 3/1.5A with Cabinet 14" x 9" x 3-1/2" Supervised Battery Charge

APS-3004C

APS-300 Power Supply in 14" x 9" Enclosure with 4 Outputs

APS-300FT

APS-300 Power Supply in 14" x 9" Enclosure with EOL Fire Relay
