Model 1200WP

1200 lbs Weather-Proof Magnetic Gate Lock

Specifications

• • 1200 lbs holding force
• • Magnet size: 9" L x 2-5/8" H x 1-5/8" W
• • Armature size: 7-1/2" L x 2-3/8" W x 9/16" W
• • Operates on 12 or 24 VDC
• • Current draw: 440 mA 12 VDC, 260 mA at 24 VDC
• • Operating temperature: +14 to +131F [-10 to +55C]
• • 0.5" ID/0.75" OD conduit fitting pipe thread

• • Use 23/64" diameter drill for blind nuts provided with lock
• • Self drilling TEC screws
• • Limited lifetime warranty

Options

• • Gate mounting brackets are available
• • Available with 600 lbs holding force. Order 600WP
• • AM6370 mounting bracket

Features

• • 10" color coded wire leads in plastic jacket
• • Non-aluminum parts are plated to resist corrosion
• • Top mount or side mount
• • Completely sealed in stainless steel case

Models

1200WP

1200 lbs Weather-proof Magnetic Lock, 12 or 24 VDC
