Components - Mix and match up to 1 door station and 4 master stations

Door Stations - Select 1

LE-D Audio Door

Station Plastic chassis
Surface mount
· Fits 1-gang box 4-3/4"H 3-7/16"W 1-1/8"D

LE-SS-1G Audio Door

Station Stainless

steel panel Flush mount
Fits 1-gang box 4-1/2"H 2-3/4"W 2-1/2"D (back box depth)

LE-DA

Audio Door Station

Stainless steel cover
Flush mount
Fits 2-gang box 4-1/2"H 4-9/16"W 2-1/2"D (back box depth)

LE-SS/A Audio Door

Station Stainless
steel panel Flush mount
Fits 2-gang box 4-3/4"H 4-3/4"W 2-1/2"D (back box depth)

LE-SSR

Audio Door Station

Red mushroom call button
Stainless steel panel
Flush mount
Fits 2-gang box 4-3/4"H 4-3/4"W 2-1/2"D (back box depth)

• Built-in CCTV

steel panel

Flush mount

• Fits 2-gang box

(back box depth)

Audio Door Station

LE-SSV

camera

Stainless

4-3/4"H

4-3/4"W

2-1/2"D

LS-NVP/C

Audio Door Station

Powder-coated steel panel
Flush mount
Fits 3-gang box 7-1/2"H 5-1/2"W 2-1/2"D (back box depth)

NOTE: Aiphone recommends a 2-1/2" minimum back box depth for all flush mount door stations.

Master Stations - Select up to 4

LEM-1DL

Audio Master Station (requires 1 DAK-2S per every 2 master stations in the system)

· Door release button
Surface mount 7-1/16"H 5-5/8"W 2-1/8"D

LEM-1DLC

Audio Master Station

Multi-master (max. 4)
Door release button
Occupied LED
Surface mount 7-1/16"H 5-5/8"W 2-1/8"D

Starter Kit - Includes door station, master station, and transformer (up to 3 additional master stations can be installed for door answering)

LEM-1DLS

Box Set Starter Kit Includes:

1 LEM-1DL Master Station
1 LE-D Door Station
1 PT-1210N Transformer

Power Supply

PT-1210N 12V AC Transformer

(required for system -

1 per master station)

Accessories

HID-SS

Card Access Station with HID® ProxPoint® Plus Proximity Card Reader (requires a 3rd party host)

KMB-45 45° Mullion Mounting Bracket for LE-D

SBX-1G Surface Mount Box for LE-SS-1G

SBX-2G Surface Mount Box for LE-DA. LE-SS/A, or LE-SSR

SBX-2BH Horizontal Surface Mount Box for HID-SS and one LE-DA. LE-SS/A, or LE-SSR

SBX-NVP Surface Mount Box for LS-NVP/C

BBX-1E Flush Mount Back Box for LF-R or LE-BN

Specifications

Spec▼ \| Model►	LEM-1DL, LEM-1DLC
Power Source	12~16V AC - use PT-1210N, 12~24V DC, 200mA
Output	100mW
Wire Type	Door Station to Master Station: 2 cond., overall shield (Aiphone wire #822202 or #821802) Between LEM-1DLCs: 3 cond., overall shield (Aiphone wire #822203 or #821803)
Wire Distance	Door Station to farthest Master Station: 6501(22AWG) 1 6001(18AWG)
