Features & Benefits

• 3x5 station capacity Create the desired entry security and communication solution with up to 3 door stations and 5 master stations.
• Visitor screening See and speak with visitors to determine their intent before letting them inside.
• Door release Conveniently unlock the door after visitors are confirmed – with the push of a button!

• Audio/Video monitoring Discreetly monitor activity in areas where door stations are installed.
• Selective and All Call Choose to call one master or sub master station at a time or call all of them at once.
• Designed to last Install the KB Series system and have years of reliable quality.

Components

Door Stations - Mix and match up to 3 (max. 1 audio door station per system)

KB‑DAR Video Door Station

• Tilt camera
• Plastic chassis
• Weather resistant
• Surface mount 5-1/2" H
• 4-1/8" W 1-3/4" D

KB‑DAR‑M Video Door Station

• Motion detector contact input
• Tilt camera
• Plastic chassis
• Weather
• resistant • Surface mount 5-1/2" H
• 4-1/8" W 1-3/4" D

AX‑DM Audio Door Station

• Plastic chassis
• Weather resistant
• Mullion surface mount 6-5/16" H 1-11/16" W 7/8" D

IF‑DA Audio Door Station

• Plastic chassis
• Weather resistant
• Surface mount 5-1/8" H 3-7/8" W 1-1/8" D

IE‑JA Audio Door Station

• Stainless steel cover
• Weather resistant
• Flush mount
• Fits 2‑gang box 4-1/2" H 4-9/16" W 2-1/2" D (back box depth)

IE‑SS/A Audio Door Station

• Stainless steel panel
• Weather and vandal resistant
• Flush mount
• Fits 2‑gang box 4-3/4" H 4-3/4" W
• 2-1/2" D (back box depth)

IE‑SSR Audio Door Station

• Red mushroom call button
• Stainless steel panel
• Weather and vandal resistant
• Flush mount
• Fits 2‑gang box 4-3/4" H 4-3/4" W 2-1/2" D (back box depth)

Components

Master Station & Power Supply

(required for system)

Video Master Station (requires PS-2420UL)

• 4" LCD screen
• Handset for privacy 7-11/16" H 7-5/16" W 3-5/16" D

PS‑2420UL

2-1/16" D

24V DC, 2A Power Supply (required for KB-3MRD and for every 2 KB-3HRDs) 6-9/16" H 3-9/16" W

Sub Master Stations - Mix and match up to 4 (max. 2 audio sub master stations per system)

Video Sub Master Station (requires PS-2420UL for every 2 KB-3HRDs)

• 4" LCD screen
• Handset for privacy 7-11/16" H 7-5/16" W 3-5/16" D

KB‑3SD

Audio Sub Master Station (max. 2 per system)

• Handset for privacy 8-1/4" H 3-15/16" W

2-7/8" D

Accessories

HID‑SS

Card Access Station with HID® ProxPoint® Plus Proximity Card Reader

SBX‑2G

Surface Mount Box for IE‑JA, IE‑SS/A, or IE‑SSR

SBX‑ACE

Surface Mount Box for AX‑DM, IF‑DA, KB‑DAR, or KB‑DAR‑M and one Access Control Device

KAW‑D

30˚ Angle Box for KB‑DAR or KB‑DAR‑M

KMB‑45

Mullion Mounting Bracket for KB‑DAR, KB‑DAR‑M, or IF‑DA

KA‑DGR

Surface Mount Housing Panel for KB‑DAR or KB‑DAR‑M

KA‑FSH

Flush Mount Housing Panel for KB‑DAR or KB‑DAR‑M

EL‑12S

Electric Door Strike (requires PT-1210N)

PT‑1210N

12V AC Transformer (required for EL-12S)

IER‑2

Call Extension Speaker

RY‑24L

Form C Door Release Relay (for 1 door)

RY‑3DL

Selective Door Release Adaptor (for 2 or 3 doors)

RY‑ES

External Signaling Relay

MAW‑B

Auxiliary Light Control Relay

MCW‑S/A

Desk Stand for KB‑3MRD or KB‑3HRD

Specifications

Power Source	24V DC – use PS‑2420UL	Communication Handset (full-duplex)
Door Release	N/O dry contact, 12V AC, 400mA – use EL‑12S (use RY‑24L for larger contact rating or RY‑3DL for 2 or 3 doors)
Wire Type	2‑cond., mid cap, solid, non‑shielded – use Aiphone #871802
	Master Station to Door Station: 330'(22AWG) 650'(18AWG)
Wire Distance	Master Station to farthest Sub Master Station: 165'(22AWG) 330'(18AWG)
	Power Supply to Master Station or Sub Master Station: 16'(22AWG) 33'(18AWG)
