IS SERIES Flexible Hardwired Intercom with IP Capability

Control & Interface Units

IS-CCU

Central Control Unit

• Supports up to 4 master stations and 4 door/sub/room stations
• 8 dry contacts (up to 4 can be used for door release)

IS-SCU

Add-On Central Control Unit

• Supports up to 8 master stations and 8 door/sub/room stations
• · 4 dry contacts

IS-RCU

Room Station Control Unit

• Supports up to 30 audio sub/room stations
• 4 dry contacts

IS-IPC

Network/Phone Interface Unit

• Connects multiple hardwired systems over a network
• Provides a telephone line connection to forward calls from hardwired door/sub/room stations

Master Stations & PC Software

IS-MV/IS-IPMV

Video Master Station

• IP addressable, PoE or 24V DC (IS-IPMV only)
• 3-1/2" LCD screen
• Hands-free communication with handset for privacy
• Wall or desk mount (stand included)

IS-SOFT

PC Master Station Software (requires one IS-IP device)

Room Station

IS-RS

Audio Room Sub Station

• Hands-free communication with handset for privacy
• Indoor use
• Surface mount

Door Stations

IS-DV/IS-IPDV

Video Door Station

• IP addressable, PoE or 24V DC (IS-IPDV only)
• PTZ camera
• Aluminum die cast cover
• Weather and vandal resistant
• Surface mount

IS-DVF-RP10/

Card Access

IS-IPDVF-RP10

Video Door Station

(IS-IPDVF-RP10 only)

HID® multiCLASS

· Stainless steel panel

· Weather and vandal resistant

· Flush mount (back box included)

IP addressable.

PoF or 24V DC

SE® Proximity

Card Reader

PTZ camera

IS-DVF/IS-IPDVF

Video Door Station

• IP addressable, PoE or 24V DC (IS-IPDVF only)
• PTZ camera
• Stainless steel panel
• Weather and vandal resistant
• Flush mount (back box included)

• PoE or 24V DC (IS-IPDVF-HID only)
• HID® ProxPoint® Plus Proximity Card Reader
• PTZ camera
• Stainless steel panel
• Weather and vandal resistant
• Flush mount (back box included)

IS-SS Audio Door/

Sub Station

• Stainless steel panel
• Weather and vandal resistant
• Flush mount (back box included)

IS-SS-2G

Audio Door/ Sub Station

• Stainless steel panel
• Weather and vandal resistant

Flush mount

IS-SSR-2G

Audio Door/Sub Station

• Red mushroom call button
• · Stainless steel panel
• Weather and vandal resistant
• Flush mount (fits 2-gang box)

$\{\backslash it\; NOTE:\; HID\}\; \{\backslash it\; @stations\; require\; a\; 3rd\; party\; host\; and\; additional\; wire\; to\; power\; card\; reader.\}$

Components & Accessories

Emergency Stations

IS‑DVF‑2RA / IS‑DVF‑2RA‑FR (French)

ADA Compliant Video Emergency Station

• Connects to IS‑CCU or IS‑SCU
• PTZ camera
• Lettering and Braille signage
• LED call status indicator
• Dual call buttons
• 2 Form C relay outputs
• Stainless steel panel
• Weather and vandal resistant
• Flush mount (back box included)

IS‑SS‑2RA‑R

ADA Compliant Audio Emergency Station

• Connects to IS‑CCU, IS‑SCU, or IS‑RCU
• Lettering and Braille signage
• LED call status indicator
• Dual call buttons
• 2 Form C relay outputs
• Stainless steel panel
• Weather and vandal resistant
• Flush mount (back box included)

IS‑SS‑RA‑R

ADA Compliant Audio Emergency Station

• Connects to IS‑CCU, IS‑SCU, or IS‑RCU
• Lettering and Braille signage
• LED call status indicator
• Single call button
• 2 Form C relay outputs
• Stainless steel panel
• Weather and vandal resistant
• Flush mount (back box included)

Emergency Wall Boxes & Towers Power Supply & Accessories

WB‑CA

ADA Compliant Wall Box

• Cage with beacon/ strobe light
• ASSISTANCE lettering
• UL Listed electrical box
• Stainless steel enclosure with slim, 4" depth
• Wall mount

WB‑HA

Wall Box

• Hood with beacon/ strobe light
• ASSISTANCE
• UL Listed
• enclosure with slim, 4" depth

Modular Towers

• UL Listed electrical box • CCTV camera arm module with universal pipe threading

with external threads

ADA Compliant

• lettering
• electrical box • Stainless steel
• Wall mount

WB‑CE

ADA Compliant Wall Box

• Cage with beacon/ strobe light
  • EMERGENCY lettering
• UL Listed electrical box
• Stainless steel enclosure with slim, 4" depth

Mid‑Level Single‑Station, High‑Level Dual‑Station,

• Variety of configurations, including size, lettering, and colors • Zinc‑treated steel with powder coating

PS‑2420UL

24V DC, 2A Power Supply (required for beacon/strobe light with wall boxes and towers)

• Wall mount

and High‑Level Single‑Station Towers

• Built-in accessory mounting hardware

• Large, easy‑access panel on each module • Modular design provides lower freight costs and easier assembly than standard towers

WB‑HE

ADA Compliant Wall Box

• Hood with beacon/ strobe light
• EMERGENCY lettering
• UL Listed electrical box
• Stainless steel enclosure with slim, 4" depth
• Wall mount

IS‑PU‑UL

48V DC, 2A Power Supply

EL‑12S

Electric Door Strike (requires PT‑1210NA)

PT‑1210NA

Transformer

12V AC (required for EL‑12S)

IS‑MB Mullion Mounting Bracket for IS‑DV or IS‑IPDV

RY‑IP44 IP Input/Output Relay Adaptor (compatible with IP stations only –

SBX‑2G/A Surface Mount Box for IS‑SS‑2G or IS‑SSR‑2G

SBX‑IDVF

Surface Mount Box for IS‑DVF, IS‑IPDVF or IS‑SS

Surface IS‑DVF‑HID,

SBX‑ISDVFP

Mount Box for IS‑IPDVF-HID, IS‑DVF‑RP10, or IS‑IPDVF‑RP10

SBX‑IDVFRA

Surface Mount Box for IS‑DVF‑2RA, IS‑DVF‑2RA‑FR, IS‑SS‑2RA‑R, or IS‑SS‑RA‑R

LB‑SDVF Security Lock Box for IS‑DV, IS‑DVF, IS‑IPDV, IS‑IPDVF, or IS‑SS

TW‑SPL

Tower Mounting Plate for IS‑DVF, IS‑IPDVF, or IS‑SS

MB‑RF1

Retrofit Mounting Bracket for IS‑DVF‑2RA, IS‑DVF‑2RA‑FR, IS‑SS‑2RA‑R, or

(adapts emergency station

Code Blue® is a registered trademark of Code Blue Corporation. Talk‑A‑Phone® is a registered trademark of Talkaphone LLC.

IS‑SS‑RA‑R

to an existing Code Blue® or Talk‑A‑Phone® tower or wall box)

installation – TW‑MKL is recommended)

(lock not included)

L‑Bolt Mounting Kit for Modular Towers (an L‑bolt mounting kit is required for tower
