Aiphone GT Series Components & Accessories Product Sheet 2

Open the original PDF document

GT Series Versatile Multi-Tenant Security Video Intercom

Easy to customize – mix and match any combination of stations! Install up to 16 entrance stations, 4 video quard stations, and 500 tenant stations in a single-building application.

With the GT-MCX network adaptor, install up to 480 entrance stations, 96 video guard stations, and 5,000 tenant stations in a single- or multi-building application.

Tenant Stations

GT-2C

Video Tenant Master Station (requires a separate power supply – use PS-2420UL)

Video identification and monitoring with 3-1/2" LCD screen
· Hands-free communication
· Compatible with GT-D audio tenant door station

Video Tenant Sub Master Station (requires GT-2C)

· Video identification and monitoring with 3-1/2" LCD screen
· Hands-free communication
Up to 3 per GT-2C

GT-1C7

Video Tenant Station

Video identification and monitoring with 7" LCD screen
· Hands-free communication
· Sleek, slim design

GT-1M3

Video Tenant Station

Video identification and monitoring with 3-1/2" LCD screen
· Hands-free communication
· Sleek, slim design

GT-1A

Audio Tenant Station

· Hands-free communication

GT-1D Audio Tenant Station

· Handset for privacy

Mobile App Network Adaptor

Mobile App Network Adaptor (includes power supply)

1 adaptor per tenant
Provides ability to answer calls and unlock doors with GT Series smartphone app
Up to 3 mobile apps per adaptor

Video Guard Station & Optional Video Door Station

GT-MKB-N

Video Guard Station (requires separate power supply – use PS-2420UL)

NFC programming
Video identification and monitoring with 3.5" LCD screen
Compatible with JO-DV for singledoor video entry
Includes desk stand

JO-DV

Video Door Station (1 per GT-MKB-N for single-door video entry)

· Zinc die cast cover
Fixed camera
· Surface mount

Audio Tenant Door Station

GT-D

Audio Tenant Door Station (1 per GT-2C for singledoor audio entry)

· Plastic chassis
· Surface mount

Power Supply, Network Adaptor, Control Units, and Accessories

PS-2420UL 24V DC, 2A Power Supply

Network Adaptor (includes mounting rail)

Distribution Point Adaptor (includes mounting rail)

GT-BC Audio Control Unit

GT-VRC Video Control Unit

1-Way Video Distribution Adaptor

GT-4Z

4-Way Video Distribution Adaptor

GTW-VOA Video Output Adaptor

GT-HSA

Expanded Audio Control Unit with NFC Programming (includes mounting rail)

GT-VBX Expanded Video Control Unit (includes mounting rail

GTW-LC Multi-Relay Control Unit (includes mounting rail)

GT-RY External Signalling Relay

GFK-PS Urgent Call Pull Cord

AIPHONE ®

0000

Components & Accessories

Entrance Stations with Digital Scroll Buttons

Ready-to-Install Single Panel

GT-DMB-N

3-in-1 Video Entrance Station (includes PTZ camera, audio. and access keypad)

programming
Stainless steel panel
Flush mount with GF-3B (sold separately)
· Surface mount with SBX-GTDMB (sold separately)

SBX-GTDMB

3-in-1 Video Entrance Station

Designed to mount into Pedestal

Pro Model #64TOW-AIP-001-304

(available at www.pedestalpro.com)

GT-DMBN-SSP

Same features as

GT-DMB-N, plus:

Surface Mount Box for GT-DMB-N

Ready-to-Assemble Modular Kits

GTV-DES202B

Modular Video Entrance Station Kit (includes GT-DB + GT-DBP, GT-VB + GT-VP, GT-NSB + GT-NSP-L, GT-10K + GF-10KP, GF-2B + GF-2F x2, and GT Operation Plate)
