ASSA ABLOY Multi-Point Locks Comparison Chart Catalog_2500-2572

Product Comparisons Multi-Point Locks

Brought to you by ASSA ABLOY Group brands: CORBIN RUSSWIN | SARGENT

Commercial Hardware

Features

Assembly Listings

Physical Options

		ASSA ABLOY	Competition
		Corbin Russwin FE6600 Series SARGENT FM7300 Series	Schlage LM9300
Standards	ANSI/BHMA A156.37-Grade 1	Yes	Yes
	ICC 500-2014	Yes	Yes
	FEMA 361	Yes	Yes
	Florida Building Code (FBC) Certified	Yes	Yes
	UL Hurricane Certified @ 150psf (Enhanced Hurricane Protection)	Yes	Yes
	Ul Fire Rated	Yes	Yes
		7 Years	3 Years
	Warranty Mechanical Electro Mechanical	2 Years	N/A
	Design Pressure	+/- 252PSF	+/- 252PSF
	Impact	15 Lb. 2x4 Missile @100 Mph	15 Lb. 2x4 Missile @100 Mph
	Door Swing	Inswing or Outswing	Inswing or Outswing
	Door Configuration	Single; Active of Pair	Single; Active of Pair

Pair w/o Mullion:

6'0" X 7'0" Min / 8'0" X 8'0" Max

Latching On Inactive Pair 988; Inactive Pair Ives 360 Bolt: Inactive Pair

6'0" X 7'0" Min / 8'0" X 8'0" Max

Mechanical Functions 12 6 Electromechanical Functions 4 N/A Electronic Access Control Solutions 8 N/A Lever Designs Available 56 30 Standard Finishes 14 13 Rods and Latches Preinstalled In Doors Yes Yes Freewheeling/Vandal Resistant Yes Yes Electrified Monitoring Options Yes No Standard Mortise Lock Yes No Visual Indicator Option For Rods Yes No Dogging Option For Everyday Use Yes No Center Adjustablility While Door Hung Yes No Reversible Strikes Yes No

Face Head 4" Face Head Listed as an Option 4" Face Head Listed as an Option

Pair Sizes Pair w/o Mullion:

Single Sizes Single: 3'0" X 7'0" Min / 4'0" X 8'0" Max Single: 3'0" X 7'0" Min / 4'0" X 8'0" Max

Commercial Hardware

			Corbin Russwin	SARGENT	Competition
			FE6600 Series	FM7300 Series	Schlage LM9300
	Non-Keyed	Inside Passage	FE6680	FM7301	N/A
		Passage	FE6609	FM7314	LM9310
		Privacy Bath	FE6630	FM7366	N/A
		Privacy Bedroom	FE6620	FM7368	N/A
	Latchbolt Only	Classroom	n/a	n/a	LM9270
		Office Entry	n/a	n/a	LM9350
	Single Cylinder	Classroom Security	FE6618	FM7318	LM9371
Mechanical Functions		Exit/Dormitory	FE6665	FM7325	LM9325
		Storeroom	FE6624	FM7324	LM9380
	Double Cylinder	Classroom Security Intruder Deadbolt	FE6662	FM7339	N/A
		Classroom Security Intruder Aux Deadbolt	FE6672	FM7340	N/A
		Classroom Security Intruder Deadlatch	FE6673	FM7341	N/A
		Security Deadbolt	FE6675	FM7349	N/A
		Store Door	FE6622	FM7326	N/A

Disclaimer: This is a comparison for like product. This is not a legal or binding document. Consult manufacturers catalog for special detail and accuracy. N/A or unknown means either Not Available or information has not been located.
