ASSA ABLOY ACCENTRA TJ2310BC HO, TJ2300 NHO Top Jam Application Using 2388 Drop Plate Template_80-7323-0061-010
Open the original PDF document
View PDF
| Opening | Dim. A | ||||
|---|---|---|---|---|---|
| To 100° | 8 | (203) | |||
| 101° to 120° | 6-1/ | 2 (165) | |||
| *121° to 180° | 4 | (102) | |||
|
*Door/Wall/Hardware
Conditions Permitting. |
|||||
| Fastener Chart | ||||
|---|---|---|---|---|
| Jard | Fasteners | Door or Frame | Drill Sizes | |
| Stand | 1/4-20 Combination | Metal | #7(.201"dia.) tap: 1/4-20 | |
| S | Screw | Wood | 7/32"(5.54mm.) | |
| Sex nuts and bolts | Hollow Metal |
9/32"(7.00mm.) through
3/8"(9.5mm.) door face opposite to closer |
||
| Optional |
Aluminum or
Wood |
3/8"(9.50mm.) through | ||
| 0 | Through bolts and grommet nuts | All |
9/32"(7.00mm.) through
3/8"(9.50mm.) dia. × 3/8"(10mm.) deep, door face opposite to closer |
|
| Yal | e ° | ||
|---|---|---|---|
| Yale C | ommercial l | _ocks and | Hardware |
| www.y | alecommer | cial.com | |
