ASSA ABLOY ACCENTRA Parallel Rigid Application with Hold Open Arms. With or Without 3158 Drop Plate_7325-0251
Open the original PDF document
View PDFYale is a registered trademark of Yale Security Inc., an ASSA ABLOY Group company. Copyright Group company. All rights reserved. Reproduction in whol ® © 2010 Yale Security Inc., an ASSA ABLOY e or in part without the express written permission of Yale Security Inc. is prohibited.
| Opening | Dimension "A" | Dimesnsion "B" | ||
|---|---|---|---|---|
| inches | mm | inches | mm | |
| To 120° | 9-1/2 | 241 | 3-3/4 | 95 |
| Over 120°* | 7 | 178 | 1-1/4 | 32 |
PR2501 or PR2511 Door Closer With or Without 3158 Drop Plate Parallel Rigid Application With Non Hold Open or Hold Open Arms Multi-size Units
100 Yale Ave. Lenoir City,TN 37771-3226 1-800-438-1951
www.yalelocks.com
TEMPLATE NUMBER DATE
07-10 7325-0251
